凯斯零件查询(8590) - CASE IH LARGE (4 X 4) RECTANGULAR BALER (NORTH AMERICA) (1/98-12/00) (05-24) - PLUNGER CLEANER AND SCRAPER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
392 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
433-512
|
[8] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 2. |
492-11031
|
[8] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 3. |
425-105
|
[8] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 4. |
700114014
|
[1] |
SCRAPER
|
CAS
WA - left
|
| 5. |
700114015
|
[1] |
SCRAPER
|
CAS
WA - right
|
| 6. |
433-620
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 7. |
495-21044
|
[6] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 8. |
232-5316
|
[8] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 9. |
6232946
|
[4] |
BUSHING
|
CAS
Superseded by part number: 706232946
|
| 10. |
700122587
|
[2] |
SHIN
|
CAS
STRAP
|
| 11. |
700122588
|
[2] |
ANGLE
|
CAS
|
| 12. |
434-616
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 13. |
700122582
|
[1] |
SUPPORT
|
CAS
BLADE WA (Includes Item 16)
|
| 14. |
6518302
|
[2] |
SPACER
|
CAS
|
| 15. |
433-632
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 2", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 2", G5 Superseded by part number: 280661
|
| 16. |
740787
|
[2] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
