| 1. |
413-820
|
[10] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 2. |
80679
|
[20] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 3. |
705541
|
[16] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
1/2 HARDENED PLAIN WASHER
|
| 4. |
61-46224
|
[14] |
HEX SOC SCREW,FLAT, 5/8" x 1-1/2"
|
CAS
5/8-11 X 1-1/2 HSFCHCS SPECIAL
|
| 5. |
700124022
|
[4] |
COVER PLATE
|
CAS
PLATE
|
| 6. |
700124027
|
[2] |
COVER PLATE
|
CAS
PLATE PUSHER
|
| 7. |
700113188
|
[7] |
KNIFE
|
CAS
|
| 8. |
700113189
|
[7] |
BAR
|
CAS
|
| 9. |
7713829
|
[2] |
BEARING ASSY,19.56 mm ID x 63.75 mm OD
|
IH
Superseded by part number: 688282
|
| 10. |
492-11075
|
[2] |
LOCK WASHER,3/4"
|
CAS
3/4" Superseded by part number: 87340
|
| 11. |
425-1112
|
[2] |
NUT,3/4"-16, G5
|
CAS
3/4-16 H Superseded by part number: 80001689
|
| 12. |
378814R1
|
[4] |
CAP
|
IH
- hub
|
| 13. |
700113171
|
[4] |
NUT
|
CAS
1-5/16-18 STAKE NUT
|
| 14. |
700706125
|
[4] |
WASHER,33.86mm ID x 55.19mm OD x 3.17mm Thk
|
CAS
- tongued
|
| 15. |
700113170
|
[4] |
ROLLER,90.13mm OD x 51mm L
|
CAS
|
| 16. |
700113176
|
[2] |
COVER PLATE
|
CAS
PLATE
|
| 17. |
700706124
|
[4] |
BEARING ASSY,34.94mm ID x 65.11mm OD x 40.08mm W
|
CAS
BEARING ASSEMBLY
|
| 18. |
700124026
|
[4] |
SHAFT
|
CAS
|
| 19. |
700121644
|
[2] |
SUPPORT
|
CAS
WA
|
| 20. |
413-620
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 21. |
425-146
|
[2] |
JAM NUT,3/8" - 16, Gr 5
|
CAS
3/8-16 HJN Superseded by part number: 87016560
|
| 22. |
700121641
|
[1] |
PLUNGER
|
CAS
WA
|
| 23. |
700113187
|
[5] |
ANTI-WRAP PLATE
|
CAS
PLATE
|
| 24. |
413-616
|
[15] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 25. |
492-11038
|
[35] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 26. |
496-11041
|
[31] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 27. |
700113184
|
[2] |
ANGLE
|
CAS
|
| 28. |
700113178
|
[1] |
ANTI-WRAP PLATE
|
CAS
PLATE WA - right
|
| 29. |
433-816
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 X 1 RHSNB Superseded by part number: 280486
|
| 30. |
425-108
|
[8] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 31. |
700113177
|
[1] |
ANTI-WRAP PLATE
|
CAS
PLATE WA - left
|
| 32. |
434-616
|
[16] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 33. |
425-106
|
[16] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 34. |
700113185
|
[4] |
ANGLE
|
CAS
|
| 35. |
700113186
|
[2] |
ANGLE
|
CAS
|
| 36. |
433-820
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 37. |
413-628
|
[4] |
BOLT,Hex, 3/8" - 16 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 72187210, 9706689
|
| 38. |
700124023
|
[2] |
BLOCK
|
CAS
|
