沃尔沃零件查询MD40A; TMD40A; TMD40B; TMD40C; AQD40A; TAMD40A; TAMD40B; AD40B; AQAD40A; AQAD40BMiscellaneous EquipmentHeat Exchanger with Installation ComponentsEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
687 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
846270
|
[1] |
Heat exchanger kit
|
|
| 2. |
7744060_127
|
|
heat exchanger and termostat with installation comps
|
|
| 2. |
|
|
|
|
| 3. |
845138
|
[1] |
Bracket
|
|
| 4. |
845137
|
[1] |
Bracket
|
|
| 5. |
955334
|
[5] |
Hexagon screw
|
|
| 6. |
941908
|
[5] |
Spring washer
|
|
| 7. |
960632
|
[2] |
Plug
|
Replaced by plug-838928 and electrode-838929.
|
| 7A. |
838929
|
[2] |
Anode
|
|
| 7B. |
838928
|
[2] |
Plug
|
|
| 8. |
957181
|
[2] |
Gasket
|
|
| 9. |
845261
|
[1] |
Exhaust pipe elbow
|
|
| 10. |
846269
|
[1] |
Tube
|
|
| 11. |
842913
|
[1] |
Sealing ring
|
|
| 12. |
845821
|
[1] |
Flange
|
|
| 13. |
845527
|
[1] |
Gasket
|
|
| 14. |
946730
|
[2] |
Hexagon screw
|
|
| 15. |
846268
|
[2] |
Tube
|
|
| 16. |
961670
|
[2] |
Hose clamp
|
|
| 17. |
944386
|
[1] |
Rubber hose
|
L=400mm
|
| 18. |
853548
|
[2] |
Hose clamp
|
(961668)
|
| 19. |
846215
|
[1] |
Vent pipe
|
|
| 20. |
846216
|
[2] |
Hollow screw
|
|
| 21. |
947282
|
[2] |
Gasket
|
|
| 22. |
907132
|
[2] |
Gasket
|
|
| 23. |
800475
|
[1] |
Plug
|
Early type
|
| 24. |
418213
|
[1] |
Flange
|
Late type
|
| 25. |
418771
|
[1] |
Gasket
|
Late type
|
| 26. |
955271
|
[2] |
Hexagon screw
|
Late type
|
| 27. |
925067
|
[4] |
O-ring
|
|
