| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT06B00001F1 | [1] | BOOM, MAIN 2.03M (STD) | |
| . . | YT06B00001F2 | [1] | BOOM, MAIN 2.03M (NIBBLER & BREAKER) | |
| . . | YT06B00001F4 | [1] | BOOM, MAIN 2.03M (ROTARY FORK) | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONBOOM, MAIN, (F1 ONLY) |
| 1-20. | YT02B01022P1 | [2] | PLATE | KOB |
| 1-21. | YT06B01002P1 | [2] | BLOCK, TAPPED | |
| 1-22. | 2416T9802 | [2] | BLOCK, TAPPED | |
| 1-23. | 2418T22821 | [1] | PLATE | |
| 2. | LE02B01008P1 | [2] | BUSHING | KOB |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONBOOM, MAIN, (F2 ONLY) |
| 3-1A. | YT02B01022P1 | [2] | PLATE | KOB |
| 3-1B. | YT06B01002P1 | [2] | BLOCK, TAPPED | |
| 3-1C. | 2416T9802 | [2] | BLOCK, TAPPED | |
| 3-1D. | 2418T22821 | [1] | PLATE | |
| 3-2. | 2416T9804 | [1] | BLOCK | KOBTapped -- 70x38x16mm |
| 3-3. | YR02B01274P1 | [1] | BLOCK | KOB |
| 3-4. | 2416T9878 | [1] | BLOCK,M10 Thd Hole - 16mm Thk x 32mm W x 60mm L | KOBTAPPED |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONBOOM, MAIN, (F4 ONLY) |
| 5-1A. | YT02B01022P1 | [2] | PLATE | KOB |
| 5-1B. | YT06B01002P1 | [2] | BLOCK, TAPPED | |
| 5-1C. | 2416T9802 | [2] | BLOCK, TAPPED | |
| 5-1D. | 2418T22821 | [1] | PLATE | |
| 5-2. | 2416T20564 | [3] | BLOCK,TAPPED | |
