神钢零件查询(BOOM) - ATTACHMENT, (2 PIECE) - SK70SR-1E & SK70SR-1ES ASN YT04-07001 (1/04-12/12) (02-002) - BOOM, FRONT (2.475M) (8 FT. 2 IN.), P/N YT05B00001F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
944 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT05B00001F1 | [1] | BOOM, FRONT 2.475M (STD) | |
| . . | YT05B00001F2 | [1] | BOOM, FRONT 2.475M (NIBBLER & BREAKER, ROTARY FORK) | |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONBOOM, FRONT, (F1 ONLY) |
| 1-27. | 2416T9878 | [5] | BLOCK,M10 Thd Hole - 16mm Thk x 32mm W x 60mm L | KOBTAPPED |
| 1-28. | YT02B01015P1 | [1] | BLOCK | KOBTAPPED |
| 1-29. | 2418T24122 | [1] | PLATE | KOB |
| 2. | LE02B01008P1 | [2] | BUSHING | KOB |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONBOOM, FRONT, (F2 ONLY) |
| 3-1A. | 2416T9878 | [5] | BLOCK,M10 Thd Hole - 16mm Thk x 32mm W x 60mm L | KOBTAPPED |
| 3-1B. | YT02B01015P1 | [1] | BLOCK | KOBTAPPED |
| 3-1C. | 2418T24122 | [1] | PLATE | KOB |
| 3-2. | 2416T3672 | [4] | BLOCK, TAPPED | |
