凯斯零件查询(8590) - CASE IH LARGE RECTANGULAR BALER (EUROPE) (1/97-12/98) (2-02) - HITCH AND JACK ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
1010 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700713921
|
[1] |
GEAR SET
|
CAS
|
| 2. |
700713889
|
[1] |
JACK
|
CAS
ASSEMBLY (Includes Ref: 1, 3, 24 and 25)
|
| 3. |
700711509
|
[1] |
CRANKED HANDLE
|
CAS
CRANK KIT
|
| 4. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 5. |
1663158
|
[1] |
RING
|
CAS
- hitch, lower
|
| 6. |
1663163
|
[10] |
SHIM
|
CAS
Superseded by part number: 701663163
|
| 7. |
762260
|
[1] |
PIN
|
CAS
1/4 X 1-3/4 KLIK PIN, chain & cp Superseded by part number: 87106279
|
| 8. |
1663159
|
[1] |
BALL
|
CAS
- hitch
|
| 9. |
1663157
|
[1] |
RING
|
CAS
- hitch, upper
|
| 10. |
61-33832
|
[8] |
HEX SOC SCREW,3/8 - 16 x 2"
|
CAS
3/8-16 X 2 HSHCS GR/8
|
| 11. |
413-1060
|
[1] |
BOLT,Hex, 5/8" - 11 x 3-3/4", Gr 5
|
CAS
5/8-11 X 3-3/4 C Superseded by part number: 16445
|
| 12. |
230-41110
|
[1] |
LOCK NUT,5/8"-11, GA
|
CAS
5/8-11 HTLN GR/B Superseded by part number: 85700693
|
| 13. |
700113646
|
[1] |
CLEVIS
|
CAS
- safety chain
|
| 14. |
700706807
|
[1] |
CHAIN
|
CAS
- safety Superseded by part number: PCC8607423
|
| 15. |
1663161
|
[2] |
PLATE
|
CAS
- hitch
|
| 16. |
1663162
|
[1] |
SPACER,19.84mm ID x 45mm OD x 90mm L
|
CAS
|
| 17. |
700124041
|
[1] |
BOLT
|
CAS
1-1/4-7 X 9 HEX BOLT - special
|
| 18. |
495-21138
|
[2] |
WASHER,1 1/4"
|
CAS
1-1/4 HARDENED PLAIN WASHER Superseded by part number: 87370
|
| 19. |
425-1020
|
[1] |
NUT,1 1/4"-7, G5
|
CAS
1-1/4-7 H Superseded by part number: 9849649
|
| 20. |
425-1420
|
[1] |
JAM NUT,Jam, 1 1/4"-7, G5
|
CAS
1-1/4-7 HJN
|
| 21. |
700716624
|
[1] |
SCREW
|
CAS
5/8-11 X 7-1/2 C GR 8 Superseded by part number: 281041
|
| 22. |
492-11062
|
[1] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 23. |
425-1010
|
[1] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 24. |
700713920
|
[1] |
KIT
|
CAS
BEARING - kit Superseded by part number: 700744720
|
| 25. |
700713922
|
[1] |
PIN
|
CAS
W/CHAIN Superseded by part number: 22139
|
