| 1. |
326-1048
|
[1] |
BOLT,Hex, 5/8" - 11 x 3", Gr 8
|
CAS
|
| 2. |
700711198
|
[1] |
LOCK NUT
|
CAS
5/8-11 HFTLN GR/G, special Superseded by part number: 84180923
|
| 3. |
700710984
|
[4] |
SCREW,Hex Flg, 1/2" x 1 1/4", G8 NC
|
CAS
1/2-13 HFTLN GR/G
|
| 4. |
231-5348
|
[4] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 5. |
700113022
|
[1] |
SUPPORT
|
CAS
- bearing
|
| 6. |
700110467
|
[1] |
BEARING ASSY,44.45 mm ID x 92.44 mm OD x 29 mm
|
L
BEARING ASSEMBLY (Includes Ref: 11)
|
| 7. |
433-820
|
[6] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 8. |
80679
|
[5] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 9. |
425-108
|
[5] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 10. |
700113039
|
[1] |
SHAFT
|
CAS
ASSEMBLY
|
| 11. |
51318
|
[1] |
BEARING
|
IH
- spherical Superseded by part number: 668718R92, 47577169
|
| 12. |
495-21056
|
[4] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 13. |
706176
|
[2] |
SCREW
|
CAS
5/16-18 X 3/4 CRTHMS
|
| 14. |
231-5145
|
[2] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 15. |
432-1016
|
[1] |
COTTER PIN,5/32" x 1"
|
CAS
5/32" x 1" Superseded by part number: 83903970
|
| 16. |
700113058
|
[1] |
BRAKE BAND
|
CAS
BRAKE ASSEMBLY (Includes Ref: 13 and 14)
|
| 17. |
413-872
|
[1] |
BOLT,Hex, 1/2" - 13 x 4-1/2", Gr 5
|
CAS
1/2-13 X 4-1/2 C Superseded by part number: 87996
|
| 18. |
700714586
|
[2] |
FLANGE NUT
|
CAS
1/2-13 HFN GR8 Superseded by part number: 329-288
|
| 19. |
700112893
|
[1] |
CHANNEL
|
CAS
- right
|
| 20. |
6524003
|
[1] |
SPACER
|
CAS
|
| 21. |
766667
|
[1] |
BOLT,1/2" - 13 x 10"
|
CAS
1/2-13 X 10 EYEBOLT
|
| 22. |
700113052
|
[1] |
STOP
|
CAS
|
| 23. |
700113057
|
[1] |
PIN
|
CAS
- trunnion
|
| 24. |
231-1448
|
[2] |
NUT,1/2"-13, GB
|
CAS
1/2-13 LHSN Superseded by part number: 87530607
|
| 25. |
27342
|
[1] |
GRIP
|
CAS
- handle
|
| 26. |
432-1224
|
[2] |
COTTER PIN,3/16" x 1-1/2"
|
CAS
3/16" x 1 1/2" Superseded by part number: 80754
|
| 27. |
413-616
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 28. |
496-11041
|
[4] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 29. |
232-5316
|
[2] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 30. |
6489231
|
[2] |
SPACER
|
CAS
|
| 31. |
700113054
|
[1] |
LEVER
|
CAS
WA - brake
|
| 32. |
434-616
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 33. |
329-286
|
[2] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 34. |
413-512
|
[1] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
C Hex, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 72187196, 87872
|
| 35. |
232-5315
|
[1] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 36. |
439-5848
|
[1] |
HEADED PIN,1/2" x 3", G5
|
CAS
1/2 X 3 CLEVIS PIN Superseded by part number: 86979987
|
