神钢零件查询(BOOM) - ATTACHMENT, (2 PIECE) - SK70SR-1E & SK70SR-1ES ASN YT04-07001 (1/04-12/12) (02-013) - HYD LINES CYLINDER JIB Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
739 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 0. | YT01V00005F1 | [1] | CYLINDER ASSY. | KOB |
| . . | YT42H00012F1 | [1] | HYD LINES, CYLINDER | |
| 1. | YT42H01125P2 | [1] | TUBE | KOBTUBE |
| 2. | YT42H01126P2 | [1] | TUBE | KOBTUBE |
| 3. | YT42H01068D1 | [2] | HOSE | KOBHOSE |
| 4. | ZA23F22008 | [1] | HYD CONNECTOR | KOB1/2" PT - M30x1.50 x 43mm Long |
| 5. | ZA33F22008 | [1] | 90 ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB90° -- 1/2" PF - M30x1.50x34mm Long (Incls. O-Ring ZD12P02400) |
| 6. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 7. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 8. | ZE82T02000 | [1] | PLUG | KOBPipe, 1.25" PT |
| 9. | YR43H01003P1 | [2] | CLAMP | KOB |
| 10. | ZS18C10050 | [2] | SCREW,Hex, M10 x 50mm | KOBM10x1.50x50mm |
| 11. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
