| 1. |
6229462
|
[2] |
SPACER
|
CAS
|
| 2. |
100-11150
|
[1] |
SNAP RING,#150, Ext
|
CAS
Ring, Snap, #150, Ext Superseded by part number: 133066
|
| 3. |
52282
|
[5] |
BUSHING
|
CAS
1-1/2 X 14 GAUGE NRMB Superseded by part number: 51200382, 51200382, NLS
|
| 4. |
700134966
|
[1] |
ARM
|
HFI
CRANK WA
|
| 5. |
231-5348
|
[8] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
1/2-13 HFTLN GR/G Superseded by part number: 86521610
|
| 6. |
1307583C1
|
[4] |
FLANGED BEARING
|
IH
|
| 7. |
50328
|
[2] |
SPHERICAL BEARING,38.1 mm ID x 80 mm OD x 18, 56.36 mm
|
CAS
- spherical
|
| 8. |
432-816
|
[1] |
COTTER PIN,1/8" x 1"
|
CAS
1/8" x 1" Superseded by part number: 80755
|
| 9. |
700134398
|
[1] |
SPACER
|
CAS
|
| 10. |
439-11032
|
[1] |
HEADED PIN,15.88mm OD x 50.8mm L
|
CAS
5/8 X 2 CLEVIS PIN
|
| 11. |
700113287
|
[1] |
LINK
|
CAS
WA
|
| 12. |
413-1040
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 280233
|
| 13. |
6845879
|
[2] |
PLUG
|
CAS
- spring
|
| 14. |
702282
|
[2] |
BOLT,Hex, 5/8" - 11 x 10", Gr 5
|
CAS
5/8-11 X 10 FTB
|
| 15. |
396-21066
|
[2] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 16. |
425-1010
|
[2] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 17. |
T54573
|
[1] |
PIN
|
IH
.120 WIRE HAIR PIN COTTER Superseded by part number: 87421748
|
| 18. |
700113296
|
[1] |
COLLAR
|
CAS
|
| 19. |
863381
|
[1] |
CLIP,9.53mm OD x 50.8mm L
|
CAS
3/8 X 2 CLEVIS PIN
|
| 20. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 21. |
700113292
|
[1] |
LINK
|
CAS
WA
|
| 22. |
432-820
|
[1] |
COTTER PIN,1/8" x 1 1/4"
|
CAS
PIN, SPLIT (COTTER), 1/8" x 1-1/4" Superseded by part number: 87395, 87778232
|
| 23. |
22754R1
|
[1] |
CLEVIS PIN,5/8" x 1.844"
|
IH
5/8 X 1-3/4 CLEVIS PIN
|
| 24. |
6522700
|
[2] |
SPRING
|
CAS
ASSEMBLY (Includes Ref: 13)
|
| 25. |
413-1080
|
[1] |
BOLT,Hex, 5/8" - 11 x 5", Gr 5
|
CAS
Superseded by part number: 88729
|
| 26. |
495-21069
|
[2] |
WASHER,5/8"
|
CAS
5/8 WIDE PLAIN WASHER Superseded by part number: 80299
|
| 27. |
232-53110
|
[2] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
