| 1. |
700113643
|
[1] |
SPROCKET
|
CAS
50B20 TOOTH
|
| 2. |
700113304
|
[1] |
SPACER
|
CAS
|
| 3. |
433-820
|
[16] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
| 4. |
700714586
|
[16] |
FLANGE NUT
|
CAS
1/2-13 HFN GR8 Superseded by part number: 329-288
|
| 5. |
700703101
|
[4] |
SPHERICAL BEARING,31.78 mm ID x 80 mm OD x 36.512 mm
|
CAS
BEARING Superseded by part number: 86523785
|
| 6. |
663562R1
|
[8] |
FLANGE
|
IH
|
| 7. |
432-1628
|
[2] |
COTTER PIN,1/4" x 1 3/4"
|
CAS
Pin, Split (Cotter), 1/4" x 1 3/4" Superseded by part number: 87041
|
| 8. |
NLS
|
[7] |
NO LONGER SERVICED
|
BAS
1-1/2 X 14 GAUGE NRMB
|
| 9. |
700113299
|
[1] |
AUGER
|
CAS
- left
|
| 10. |
700113638
|
[2] |
SPACER
|
CAS
|
| 11. |
433-512
|
[23] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 12. |
496-21034
|
[23] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 13. |
231-5145
|
[23] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 14. |
700113248
|
[1] |
AUGER FLIGHT
|
CAS
FLIGHTING - right, right hand spiral
|
| 15. |
413-1252
|
[1] |
BOLT,Hex, 3/4" - 10 x 3-1/4", Gr 5
|
CAS
3/4-10 X 3-1/4 C Superseded by part number: 88747
|
| 16. |
232-53112
|
[1] |
FLANGE NUT,Flg, 3/4"-10
|
CAS
3/4-10 HFTLN GR/G Superseded by part number: 86512372
|
| 17. |
700113636
|
[1] |
SPROCKET
|
CAS
WA 20-29 TOOTH
|
| 18. |
700113305
|
[1] |
SPACER
|
CAS
|
| 19. |
700134963
|
[2] |
PIVOT
|
HFI
WA
|
| 20. |
700113281
|
[2] |
SPACER
|
CAS
|
| 21. |
700134986
|
[1] |
PAN
|
HFI
- auger, right
|
| 22. |
700134978
|
[1] |
CHUTE
|
HFI
WA - pickup
|
| 23. |
121-226
|
[5] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 24. |
496-11041
|
[5] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 25. |
700113300
|
[1] |
AUGER
|
CAS
- right
|
| 26. |
700113247
|
[1] |
AUGER FLIGHT
|
HFI
FLIGHTING - left, left hand spiral
|
| 27. |
700134985
|
[1] |
PAN
|
HFI
- auger, left
|
