| 1. | 2420R349D190 | [1] | HOSE,6.35mm ID x 1900mm L | KOB1900mm Long (74-13/16 in) |
| 2. | 2420R349D180 | [1] | HOSE,6.35mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 3. | 2420R349D040 | [1] | HOSE,6.35mm ID x 400mm L | KOB1/4" PF, 400mm Long (15-3/4 in) |
| 4. | 2444R1120D050 | [1] | HOSE | KOB500mm Long (19-11/16 in) |
| 5. | ZN18C08007 | [1] | NUT | KOBM08x1.25mm |
| 6. | PY03M01026P1 | [1] | PIN | KOBM08x1.25x115mm Long |
| 7. | ZW16X08000 | [3] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 8. | ZS28C10020 | [2] | SCREW,Hex Socket Head, M10 x 20mm | KOBM10x1.50x20mm |
| 9. | ZW26X10000 | [2] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 10. | ZS18C10025 | [2] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 11. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 12. | 2444Z2525 | [1] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 13. | ZH32X04000 | [6] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 14. | HH35X04004G3 | [1] | 90 ELBOW | KOB90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 15. | YN30V00080F1 | [1] | VALVE | KOBAssembly, Pilot -- See Figure 08-025 |
| 16. | ZH22X04000 | [2] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 17. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 18. | YT30M01002F1 | [1] | LOCK | KOBAssembly, Right Hand |
| 19. | YN03M01265P1 | [1] | PEDAL | KOB |
| 20. | YN03M01266P2 | [1] | RUBBER SLEEVE | KOB |
| 22. | LC52S00011P1 | [1] | SENSOR | KOBPressure (Low Pressure) (Incls. O-Ring ZD12P01100) Superseded by part number: LC52S00019P1 |
| 23. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 29. | YN26V00001F2 | [1] | VALVE | KOBAssembly, Shuttle |
| 30. | ZS18C08050 | [1] | SCREW,Hex, M8 x 50mm | KOBM08x1.25x50mm |
| 31. | ZW16H08000 | [1] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 32. | HH55Q04004G1 | [2] | TEE,1/4" ORB x 1/4" JIC x 1/4" JIC | KOB1/4" PF (Incls. O-Ring ZD12P01100) |
| 33. | 2444Z4239 | [1] | TEE | KOB1/4" PT (Incls. O-Ring ZD12P01100) |
| 34. | GB50S00049F2 | [1] | SWITCH | KOBPressure (Low Pressure) |
| 35. | 2444Z3322D2 | [1] | CONNECTION | KOB1/4"PF x 1/8"PT x 27mm Long (Incls. O-Ring ZD12P01100) |
| 37. | 2420R349D170 | [1] | FLEXIBLE HOSE | KOB1700mm Long (66-59/64 in) Superseded by part number: HX21E04170DX |
| 38. | 2420R349D220 | [1] | HOSE,2200.00 mm | KOB Superseded by part number: HX21E04220DX |
| 39. | 2420R349D035 | [1] | HOSE | KOB350mm Long (13-49/64 in) |
