神钢零件查询(BOOM) - ATTACHMENT, (2-PIECE BOOM) SK135SR-1E, SK135SRLC-1E, SK135SRLC-1ES (11/01-12/10) (06-017[03]) - UPPER HARNESS ASSEMBLY, (2-PIECE BOOM), (YY13E00009F6), PAGE 3 OF 9 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
1006 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YX13E01006D1 | [1] | CABLE | KOB |
| 9. | 2432R233D1 | [2] | CLIP | KOB37x12x40mm |
| 10. | ZM61C06012 | [2] | BOLT | KOBM06x1.0x12mm (Incls. Washer & Lockwasher) |
| 14. | PY01P01043D4 | [10] | CABLE TIE,4.80mm W x 251mm L | KOBWire Ties -- 249mm Long |
| 25. | YY13E01054P4 | [1] | HARNESS | KOB |
