神钢零件查询(BOOM) - ATTACHMENT, (2-PIECE BOOM) SK135SR-1E, SK135SRLC-1E, SK135SRLC-1ES (11/01-12/10) (06-017[02]) - UPPER HARNESS ASSEMBLY, (2-PIECE BOOM), (YY13E00009F6), PAGE 2 OF 9 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
250 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 8. | ZW26X08000 | [3] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 14. | PY01P01043D4 | [10] | CABLE TIE,4.80mm W x 251mm L | KOBWire Ties -- 249mm Long |
| 16. | ZW16X08000 | [2] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 20. | 2432R233D3 | [2] | CLIP | KOB50x16x60mm |
| 21. | ZS18C08016 | [3] | SCREW,Hex, M8 x 16mm | KOBM08x1.25x16mm |
| 22. | ZW16X10000 | [1] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
