神钢零件查询(BOOM) - ATTACHMENT, (2-PIECE BOOM) SK135SR-1E, SK135SRLC-1E, SK135SRLC-1ES (11/01-12/10) (06-031[00]) - FRONT BOOM HYDRAULIC LINES, (2-PIECE BOOM), (YY42H00047F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
128 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY42H01198P1 | [1] | TUBE | KOBRight Hand |
| 2. | YY42H01199P1 | [1] | TUBE | KOBTube, Left Hand |
| 3. | ZX50H10105 | [2] | FLEXIBLE HOSE | KOB |
| 4. | ZD12A01600 | [4] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| 5. | ZC26X22011 | [4] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 6. | ZS18C10045 | [4] | SCREW,Hex, M10 x 45mm | KOBM10x1.50x45mm |
| 7. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
