| 1. |
413-528
|
[1] |
BOLT,Hex, 5/16" - 18 x 1-3/4", Gr 5
|
CAS
Superseded by part number: 9707515, 72187200
|
| 2. |
496-21034
|
[9] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 3. |
232-5315
|
[1] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 4. |
700133083
|
[1] |
SHIELD
|
HFI
|
| 5. |
700133732
|
[1] |
SHIELD
|
HFI
|
| 6. |
256873
|
[14] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 7. |
231-5145
|
[10] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 8. |
CAS758342
|
[1] |
SPRING
|
CAS
- compression
|
| 9. |
700709866
|
[1] |
WASHER
|
CAS
- washer, camloc
|
| 10. |
863381
|
[1] |
CLIP,9.53mm OD x 50.8mm L
|
CAS
3/8 X 2 CLEVIS PIN
|
| 11. |
700123830
|
[1] |
CHANNEL
|
CAS
- support Superseded by part number: 700150655
|
| 12. |
432-1012
|
[1] |
COTTER PIN,5/32" x 3/4"
|
CAS
5/32" x 3/4"
|
| 13. |
700133731
|
[1] |
SHIELD
|
HFI
|
| 14. |
700114012
|
[1] |
BEARING COVER
|
HFI
SHIELD - bearing
|
| 15. |
700133735
|
[1] |
SHIELD
|
HFI
- lower
|
| 16. |
700134443
|
[1] |
SUPPORT
|
HFI
- strap
|
| 17. |
434-616
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 18. |
329-286
|
[1] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 19. |
700133733
|
[1] |
SHIELD
|
HFI
WA - PTO
|
| 20. |
65052
|
[1] |
SPACER
|
NNA
- hinge Superseded by part number: 065052, 065052, NLS
|
| 21. |
700714528
|
[1] |
LATCH
|
CAS
- 1/4 turn Superseded by part number: 292505A1
|
| 22. |
700133741
|
[1] |
SHIELD
|
HFI
WA - flywheel
|
| 23. |
121-108
|
[5] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
| 24. |
492-11031
|
[7] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 25. |
425-105
|
[7] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 26. |
700113994
|
[3] |
HINGE
|
CAS
SUPPORT - hinge
|
| 27. |
700707203
|
[1] |
CAPTIVE WASHER SCREW
|
CAS
#12-24 X 3/4 HWHMS
|
| 28. |
1954816C1
|
[1] |
LOCK NUT
|
IH
#12-24 HCLN SPECIAL Superseded by part number: 848083
|
| 29. |
700708648
|
[1] |
BUMPER
|
CAS
|
| 30. |
700133737
|
[1] |
SUPPORT
|
HFI
- latch
|
| 31. |
340-1108
|
[2] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
#10-24 X 1/2 CRPHMS GR60M
|
| 32. |
195-513
|
[2] |
WASHER,#10
|
CAS
PLAIN WASHER #10 Superseded by part number: 9824326
|
| 33. |
492-11010
|
[2] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 34. |
225-14110
|
[2] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 35. |
700714529
|
[1] |
SOCKET/RECEPTACLE
|
CAS
RECEPTACLE Superseded by part number: 292504A1
|
| 36. |
121-115
|
[2] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 37. |
7894967
|
[1] |
HANDLE
|
CAS
|
| 38. |
700133740
|
[1] |
CHANNEL
|
HFI
|
| 39. |
7758212
|
[1] |
SPRING
|
CAS
- compression
|
| 40. |
7894975
|
[1] |
CLIP
|
CAS
|
