| 1. |
700114022
|
[2] |
CHANNEL
|
CAS
ANGLE
|
| 2. |
121-115
|
[30] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 3. |
231-5145
|
[30] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 4. |
700113952
|
[1] |
SHIELD
|
CAS
ASSEMBLY - front (Includes decal)
|
| 5. |
700113953
|
[1] |
SHIELD
|
CAS
- top
|
| 6. |
700133635
|
[1] |
SHIELD
|
HFI
ASSEMBLY (Includes safety tread)
|
| 7. |
700133709
|
[1] |
LID
|
HFI
ASSEMBLY (Includes safety tread)
|
| 8. |
413-512
|
[1] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
C Hex, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 72187196, 87872
|
| 9. |
496-21034
|
[2] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 10. |
231-1445
|
[1] |
NUT,5/16"-18, GB
|
CAS
NUT, LOCK, 5/16"-18, GB Superseded by part number: 86050277
|
| 11. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 12. |
496-11041
|
[8] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 13. |
492-11038
|
[8] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 14. |
425-106
|
[8] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 15. |
700133711
|
[1] |
CHANNEL
|
HFI
ASSEMBLY (Includes safety tread)
|
| 16. |
434-616
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 17. |
413-816
|
[2] |
BOLT,Hex, 1/2" - 13 x 1", Gr 5
|
CAS
Superseded by part number: 87909, BN50282
|
| 18. |
230-4118
|
[2] |
LOCK NUT,1/2"-13, GA
|
CAS
1/2-13 HTLN GR/B
|
