| 1. |
6514772
|
[4] |
SPACER
|
CAS
|
| 2. |
413-512
|
[2] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 5
|
CAS
C Hex, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 72187196, 87872
|
| 3. |
496-21034
|
[6] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 4. |
492-11031
|
[10] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 5. |
425-105
|
[10] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 6. |
121-115
|
[38] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 7. |
231-5145
|
[38] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 8. |
413-520
|
[1] |
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
|
CAS
5/16-18 X 1-1/4 C Superseded by part number: 87657
|
| 9. |
700133106
|
[2] |
LOCKING TAB
|
HFI
CHANNEL - mounting, latch
|
| 10. |
700133626
|
[1] |
SHIELD
|
HFI
- left
|
| 11. |
432-812
|
[6] |
COTTER PIN,3/4" OAL x 1/8" W
|
CAS
PIN, SPLIT (COTTER), 1/8" x 3/4" Superseded by part number: 80756
|
| 12. |
700133624
|
[2] |
DOOR
|
HFI
WA
|
| 13. |
700714528
|
[4] |
LATCH
|
CAS
- 1/4 turn Superseded by part number: 292505A1
|
| 14. |
700113991
|
[2] |
ROD
|
CAS
- door
|
| 15. |
700113992
|
[2] |
GUIDE
|
CAS
|
| 16. |
700121720
|
[1] |
SHIELD
|
HFI
- inside
|
| 17. |
434-512
|
[5] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 280497, 87779118
|
| 18. |
700113997
|
[1] |
SUPPORT
|
CAS
WA
|
| 19. |
700121722
|
[1] |
SUPPORT
|
HFI
|
| 20. |
700709979
|
[1] |
SHIELD
|
ZED
- rubber
|
| 21. |
111-237
|
[8] |
CARRIAGE BOLT,Short NK, 5/16"-18 x 1", G5
|
CAS
BOLT, CARRIAGE, Short NK, 5/16"-18 x 1", G5 Superseded by part number: 33-516
|
| 22. |
232-5315
|
[6] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 23. |
700133630
|
[1] |
SHIELD
|
HFI
- lower, left
|
| 24. |
700121724
|
[1] |
SUPPORT
|
HFI
|
| 25. |
433-512
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 26. |
230-4115
|
[2] |
LOCK NUT,5/16"-18, GA
|
CAS
5/16-18 HTLN GR/B Superseded by part number: 230-4145
|
| 27. |
700121497
|
[1] |
STRAP
|
CAS
|
| 28. |
700133628
|
[1] |
ANGLE
|
HFI
- latch
|
| 29. |
700133632
|
[1] |
SHIELD
|
HFI
- left
|
| 30. |
700113990
|
[1] |
ANGLE
|
CAS
- lower
|
| 31. |
700113989
|
[2] |
ANGLE
|
CAS
|
| 32. |
121-226
|
[10] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 33. |
231-5146
|
[10] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 34. |
700133634
|
[1] |
PANEL
|
HFI
- step
|
| 35. |
700133639
|
[1] |
SHIELD
|
CAS
- left Superseded by part number: 700152204
|
| 36. |
700133619
|
[1] |
SHIELD
|
CAS
WA - left
|
| 37. |
700714529
|
[4] |
SOCKET/RECEPTACLE
|
CAS
RECEPTACLE Superseded by part number: 292504A1
|
| 38. |
700133623
|
[1] |
LATCH
|
HFI
MOUNTING - latch
|
| 39. |
340-1108
|
[8] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
#10-24 X 1/2 CRPHMS
|
| 40. |
195-513
|
[8] |
WASHER,#10
|
CAS
PLAIN WASHER #10 Superseded by part number: 9824326
|
| 41. |
492-11010
|
[8] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 42. |
225-14110
|
[8] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
