| 1. |
121-115
|
[21] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 2. |
231-5145
|
[34] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 3. |
8021693
|
[2] |
CABLE
|
CAS
|
| 4. |
700133160
|
[2] |
SUPPORT
|
CAS
- latch
|
| 5. |
700714529
|
[6] |
SOCKET/RECEPTACLE
|
CAS
RECEPTACLE Superseded by part number: 292504A1
|
| 6. |
340-1108
|
[12] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
#10-24 X 1/2 CRPHMS
|
| 7. |
195-513
|
[12] |
WASHER,#10
|
CAS
PLAIN WASHER #10 Superseded by part number: 9824326
|
| 8. |
492-11010
|
[12] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 9. |
225-14110
|
[12] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 10. |
700133668
|
[1] |
SHIELD
|
HFI
|
| 11. |
163-41
|
[3] |
SCREW,Sl Hex Wshr Hd, 5/16" - 18 x 1 1/4"
|
CAS
5/16-18 X 1-1/4 HWHMS
|
| 12. |
121-226
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 13. |
231-5146
|
[2] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 14. |
700714528
|
[6] |
LATCH
|
CAS
- 1/4 turn Superseded by part number: 292505A1
|
| 15. |
700133662
|
[1] |
CAP
|
HFI
WA - end, right
|
| 16. |
700133666
|
[1] |
FRAME
|
HFI
- right
|
| 17. |
7894975
|
[2] |
CLIP
|
CAS
|
| 18. |
7758212
|
[2] |
SPRING
|
CAS
- compression
|
| 19. |
496-21034
|
[4] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 20. |
6564595
|
[2] |
STOP
|
CAS
- door
|
| 21. |
7894967
|
[2] |
HANDLE
|
CAS
|
| 22. |
121-108
|
[4] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 X 1 HWHMS
|
| 23. |
700133667
|
[1] |
DOOR
|
HFI
- top
|
| 24. |
700133664
|
[4] |
SUPPORT
|
HFI
- receptacle
|
| 25. |
434-512
|
[8] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 5/16"-18 x 3/4", G5, Full Thd Superseded by part number: 280497, 87779118
|
| 26. |
700122881
|
[1] |
PIN
|
CAS
- hinge
|
| 27. |
700133665
|
[1] |
FRAME
|
HFI
- left
|
| 28. |
700133659
|
[1] |
CAP
|
HFI
WA - end, left
|
| 29. |
495-61034
|
[14] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
5/16 WIDE PLAIN WASHER
|
| 30. |
232-5315
|
[2] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
