| 1. |
700133669
|
[1] |
LADDER
|
HFI
WA
|
| 2. |
434-616
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 3. |
231-5146
|
[19] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 4. |
154273C1
|
[2] |
BOLT,Hex Serr, 3/8" - 16 x 1", Spcl
|
IH
3/8-16 X 1 HFSS Superseded by part number: 9706726
|
| 5. |
121-226
|
[6] |
SERRATED BOLT,Hex, 3/8" - 16 x 1"
|
CAS
Superseded by part number: 87034804
|
| 6. |
121-115
|
[14] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 7. |
231-5145
|
[16] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 8. |
6844682
|
[2] |
BRACKET
|
CAS
|
| 9. |
700114048
|
[1] |
SHIELD
|
CAS
WA - left
|
| 10. |
700114037
|
[1] |
SUPPORT
|
CAS
WA - left
|
| 11. |
700133642
|
[1] |
SHIELD
|
HFI
|
| 12. |
409-7524
|
[2] |
BOLT,Hex Flg, 5/16" - 18 x 1 1/2", Spcl
|
CAS
5/16-18 X 1-1/2 HFSS Superseded by part number: 86512170
|
| 13. |
700133641
|
[1] |
SHIELD
|
HFI
|
| 14. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 15. |
492-11038
|
[2] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 16. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 17. |
496-21034
|
[20] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 18. |
7702079
|
[1] |
SCREW
|
CAS
3/8-16 X 2-1/2 HFS GR8
|
| 19. |
58644
|
[1] |
SPRING
|
CAS
- compression
|
| 20. |
700121607
|
[1] |
HANDLE
|
HFI
Superseded by part number: 700151957, 700151958
|
| 21. |
700121606
|
[1] |
PLATE
|
HFI
Superseded by part number: 700600698
|
| 22. |
409-7612
|
[4] |
BOLT,3/8"-16 x 1.09" OAL
|
CAS
3/8-16 X 3/4 HWHMS Superseded by part number: 72187187, 255918
|
