神钢零件查询(BOOM) - ATTACHMENT, (2-PIECE BOOM) SK135SR-1E, SK135SRLC-1E, SK135SRLC-1ES (11/01-12/10) (06-041[00]) - ARM CYLINDER HYDRAULIC LINES, (2-PIECE BOOM), (YY43H00052F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
238 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY42H01208P1 | [1] | TUBE | KOBTube, Rod End |
| 2. | YY42H01189P1 | [1] | TUBE | KOBTube, Tube End |
| 3. | ZX20H10105 | [1] | HOSE | KOB1050mm Long (41-21/64 in) |
| 4. | ZX20H12105 | [1] | HOSE | KOB1050mm Long (41-21/64 in) |
| 5. | YY42H01191P1 | [1] | BAND | KOBBand |
| 6. | YY42H01190P1 | [1] | BAND | KOBBand |
| 7. | ZC27X22012 | [1] | COLLAR | HIT |
| 8. | ZC27X28012 | [1] | CLAMP | KOB Superseded by part number: YN43H01097P1 |
| 9. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 10. | ZS28C10035 | [8] | SCREW,Hex Socket Head, M10 x 35mm | KOBScrew -- M10x1.50x35mm |
| 11. | ZS18C10050 | [1] | SCREW,Hex, M10 x 50mm | KOBM10x1.50x50mm |
| 12. | ZS18C10055 | [1] | SCREW,Hex, M10 x 55mm | KOBM10x1.50x55mm |
| 13. | ZW26X10000 | [4] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 16. | ZD12P02600 | [2] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 17. | ZD12A01600 | [1] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| 18. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 19. | ZH22Z04000 | [1] | HYD CONNECTOR | KOB1/4"PTx1/4"PFx37mm Long |
| 20. | ZG91S02000 | [1] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
