神钢零件查询(BOOM) - ATTACHMENT, (2-PIECE BOOM) SK135SR-1E, SK135SRLC-1E, SK135SRLC-1ES (11/01-12/10) (06-037[00]) - SHORT ARM ASSEMBLY, 2.1M (6FT 11IN), (2-PIECE BOOM) (YY12B00225F1 & YY12B00219F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
649 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | YY12B01360F1 | [1] | Link Assembly, Bucket | |
| A1-1. | NSS | [1] | NOT SOLD SEPARAT | CONLink, Bucket |
| A1-2. | LP12B01036P1 | [2] | BUSHING | KOB |
| A1-3. | LP12B01031P1 | [2] | BUSHING | KOB |
| A2. | YY12B01245P1 | [1] | Link | |
| A3. | YY12B01246P1 | [1] | Link | |
| A4. | YY12B01231P1 | [2] | Pin | |
| A5. | YY12B01232P1 | [1] | Pin | |
| A6. | YY12B01233P1 | [1] | PIN | KOBPin |
| A7. | HS18C14115G2 | [2] | BOLT,Hex, M14 x 115mm, Cl 10.9 | KOBM14x2.0x150mm |
| A8. | ZN18C14011 | [4] | NUT | KOBM14x2.0mm |
| A9. | 2445R220D2 | [4] | SEAL,65mm ID x 80mm OD x 5mm Thk | KOBDust -- ID 65 x OD 80 x Th 5mm Superseded by part number: 84499663 |
| A10. | 2445R138D3 | [6] | SEAL,60mm ID x 75mm OD x 4mm Thk | KOBSeal, Dust -- ID 60 x OD 75 x Th 4mm |
| A11. | 2445R138D6 | [2] | SEAL,70mm ID x 85.3mm OD x 4mm Thk | KOBSeal, Dust -- ID 70 x OD 85 x Th 4mm |
| A13. | ZG91S02000 | [4] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| A14. | ZG91U02000 | [1] | LUBE NIPPLE | KOB90° x 1/8" PT |
| A15. | YN12B01610D1 | [6] | SHIM | KOBID 62 x OD 100 x Th 2.0mm |
| A16. | B16T0442D56 | [6] | SHIM,62mm ID x 100mm OD x 0.5mm Thk | KOBID 62 x OD 100 x Th 0.5mm |
| A17. | B16T0442D43 | [6] | SHIM,62mm ID x 100mm OD x 0.9mm Thk | KOBID 62 x OD 100 x Th 0.9mm |
| A18. | B16T0442D19 | [6] | SHIM,62mm ID x 100mm OD x 1.6mm Thk | KOBID 62 x OD 100 x Th 1.6mm |
| B1. | NSS | [1] | NOT SOLD SEPARAT | CON |
| B2. | YY12B01356P1 | [2] | BUSHING | KOBBushing |
| B3. | YW12B01042P1 | [2] | BUSHING | KOB |
| B4. | YX12B01021P1 | [2] | BUSHING | KOB |
