| . . | YY03H00030F1 | [1] | LINE | KOB |
| 1. | YY03H01062P1 | [1] | BRACKET | KOB |
| 2. | 24100P1005F3 | [1] | HYDRAULIC VALVE | KOB |
| 2-4. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 2-6. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 2-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 2-8. | ZD75G04000 | [1] | BACK-UP RING | KOBID 40 x OD 45 x Th 1.25mm |
| 2-9. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 2-10. | ZD85G03500 | [1] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| 2-12. | YY03H01143P1 | [1] | VALVE BODY | KOB |
| 2-13. | YY03H01144P1 | [1] | VALVE | KOBSHAFT |
| 2-15. | YY03H01145D1 | [1] | SPACER | KOB |
| 2-16. | ZS28C06010 | [1] | CAPSCREW,Hex Socket Head, M6 x 10mm | KOBSCREW M06x1.0x10mm |
| 3. | YX03H01075P1 | [1] | BUSHING | KOB |
| 4. | YV03H01039P1 | [1] | CONNECTION | KOB1" PF x 3/4" PF x 55.5mm Long (Incls. O-Ring ZD12P02400) |
| 4-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 5. | ZG23F10012 | [2] | HYD CONNECTOR | KOB5/8"-3/4" PT (Incls. O-Ring ZD12P02400) |
| 5-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 7. | 2444R596D6 | [1] | ELBOW | KOB90° -- 1" PF |
| 8. | ZG33F10012 | [1] | 90 ELBOW,1"-14 UNS x PF 3/4" | KOB90° -- 1" -14UNS - PF 3/4 (Incls. O-Ring ZD12P02400) |
| 8-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 9. | ZG33F12012 | [1] | 90 ELBOW,1 3/16"-12 UN x PF 3/4" | KOB90° -- 1-3/16" -12UN x 3/4" PF (Incls. O-Ring ZD12P02400) |
| 9-1. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 10. | ZD12A01600 | [3] | O-RING | KOBID 15.60 ± 0.12 x OD 19.16mm |
| 11. | ZD12A01800 | [1] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 12. | YV03H01053P1 | [1] | HOSE | KOB |
| 13. | YX03H01045D7 | [1] | HOSE | KOB |
| 14. | YY03H01063P1 | [1] | HOSE | KOB |
| 15. | YX06H01003D2 | [1] | HOSE | KOB850mm Long (33-29/64 in) |
| 16. | ZS18C08025 | [4] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 17. | ZS18C12030 | [3] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 18. | ZW16H08000 | [4] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 19. | ZW16H12000 | [4] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 20. | YX03H01046P1 | [1] | CLIP | KOBWire, Tie -- 564mm Long (22-13/64 in) |
| 21. | 2444Z2760 | [1] | HYD CONNECTOR | KOB1" PFx56.5mm Long (Incls. O-Ring ZD12P02900) |
| 21-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 22. | YX32H01011P1 | [1] | BUSHING,33mm ID x 49mm OD x 50mm L | KOBID 33 x OD 43 x 50mm Long |
| 23. | ZC46X46014 | [1] | CLIP | KOBClamp -- Ø46mm Single Cable |
| 24. | ZS18C12020 | [1] | SCREW,Hex, M12 x 20mm | KOBM12x1.75x20mm |
| 25. | YV20T01007P1 | [1] | LABEL | KOB |
