| . . | YY03H00052F1 | [1] | HYD LINES, UPP | |
| 1. | ZX25M08215 | [1] | HOSE | KOB |
| 2. | ZX25M08210 | [1] | HOSE ASSY. | KOB |
| 3. | ZX45M08060 | [1] | HOSE ASSY. | KOB |
| 4. | YN20M01046D7 | [1] | PROTECTIVE SLEEVE,22.10mm ID x 27.00mm OD x 1100.00mm | KOBProtective Plastic |
| 6. | ZX25M08120 | [1] | FLEXIBLE HOSE | KOB |
| 7. | YR03H01121P1 | [2] | CONNECTION | KOB(Incls. O-Ring ZD12P01800) |
| 7-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 8. | ZX45M08052 | [1] | HOSE | KOB |
| 9. | YX03H01046P1 | [1] | CLIP | KOBWire, Tie -- 564mm Long (22-13/64 in) |
| 10. | YX03H01051P1 | [1] | BUSHING | KOB |
| 11. | ZH22X08000 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 11-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 12. | 2444Z3713 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 12-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 13. | ZS18C12030 | [2] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 15. | ZH32X08000 | [6] | 90 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 90° -- 1/2"PT (Incls. O-Ring ZD12P01800) |
| 15-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 16. | YV03H01048P2 | [1] | U-BRACKET | KOB |
| 17. | ZW16H12000 | [2] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 18. | ZH42X08000 | [2] | 45 ELBOW,Male, 30 Degree Fl, PF 1/2" x PF 1/2", O-Ring | KOBElbow, 45° -- (Incls. O-Ring ZD12P01800) |
| 18-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 19. | 2444Z3155 | [1] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB90° -- (PF 3/8) (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 Superseded by part number: YT42H01128P1 |
| 20. | 2444Z3715 | [1] | 90 ELBOW | KOB90° -- 1/2" PF x 56mm Long (Incls. O-Ring ZD12P01800) |
| 20-1. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 21. | ZE72X04000 | [1] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 24. | HH25R08004G1 | [1] | HYD CONNECTOR | KOB1/4"PFx1/2"PFx36mm Long (Incls. O-Ring ZD12P01800) |
| 25. | HH55Q08008G1 | [1] | TEE | KOB |
| 26. | HH55Q08008G3 | [2] | TEE,PF 1/2" x PF 1/2", O-Ring | KOB(PF 1/2) (Incls. O-Ring ZD12P01800) |
| 27. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 28. | YY20V00003F1 | [1] | VALVE | KOB |
| 29. | LC52S00012P1 | [1] | SENSOR | KOBPressure (High Pressure) (replaced by LS52S00015P1) Superseded by part number: YY52S00033F1 |
| 29. | LS52S00015P1 | [2] | SENSOR | KOB(New part #) (Added by SB S030-41-K003) |
| 29-0. | YY52S00033F1 | [1] | PRESSURE SWITCH | KOBKit Includes Ref 29 - 29-3 (Refer to SB S030-41-K003) |
| 29-1. | LS30H01024P1 | [1] | HYD CONNECTOR | SM(Added with new part # press switch) |
| 29-2. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 29-3. | YT42H01128P1 | [1] | 90 ELBOW | KOB(Added with new part # press switch) |
| 30. | HH25R08008G1 | [1] | HYD CONNECTOR | KOB1/2" PF (Incls. O-Ring ZD12P01800) 106mm Long |
| 30-1. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 31. | ZA23F18008 | [2] | HYD CONNECTOR | KOB1/2" PF - M26x1.50x41mm Long (No O-Ring supplied) |
| 32. | ZD12P01800 | [2] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 33. | YY03H01123P1 | [1] | TUBE | KOB |
| 34. | PY30H01008P1 | [1] | TEE,PF 1/2" x PF 1/2" | KOB |
