| 1. |
700112840
|
[1] |
RAKE
|
CAS
FINGER WA - stuffer
|
| 2. |
485-13816
|
[1] |
SET SCREW,Sq Hd, 3/8"-16 x 1"
|
CAS
3/8-16 X 1 CPSQHSS Superseded by part number: 84983
|
| 3. |
413-836
|
[2] |
BOLT,Hex, 1/2" - 13 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 87975
|
| 4. |
80679
|
[6] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 5. |
425-108
|
[6] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 6. |
6201404
|
[1] |
KEY
|
CAS
5/16 X 5/16 X 3-3/4 KEY
|
| 7. |
425-1118
|
[1] |
NUT,1 1/8"-12, G5
|
CAS
1-1/8-12 H
|
| 8. |
413-624
|
[4] |
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 72187209, 88044
|
| 9. |
492-11038
|
[4] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 10. |
425-106
|
[4] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 11. |
700134416
|
[1] |
LEVER
|
CAS
ARM ASSEMBLY (Includes Ref: 15) Superseded by part number: 700150743
|
| 12. |
7713837
|
[1] |
CAM FOLLOWER
|
CAS
BEARING - cam, roller
|
| 13. |
219-17
|
[1] |
LUBE NIPPLE,3/16" NPTF
|
CAS
NIPPLE, LUBE, , Push 3/16" x .55" lg, Drive Superseded by part number: 80722
|
| 14. |
432-1632
|
[1] |
COTTER PIN,1/4" x 2"
|
CAS
Pin, Split (Cotter), 1/4" x 2" Superseded by part number: 88182
|
| 15. |
D46620
|
[1] |
BEARING,31.76 mm ID x 50.81 mm OD x 23.81 mm
|
CAS
BUSHING Superseded by part number: 70668028
|
| 16. |
7758758
|
[1] |
SPRING
|
CAS
- extension
|
| 17. |
7852148
|
[1] |
RING, SNAP
|
IH
RING - retaining
|
| 18. |
52324
|
[2] |
BUSHING
|
CAS
1-1/4 X 10 GAUGE NRMB Superseded by part number: 052324
|
| 19. |
700112860
|
[1] |
CRANK
|
CAS
WA - right
|
| 20. |
766113
|
[2] |
CLEVIS
|
CAS
(Includes pins) Superseded by part number: 51200283, 51200283, NLS
|
| 21. |
700112892
|
[2] |
BUSHING,101.21mm ID x 111.12mm OD x 44.45mm L
|
CAS
BEARING
|
| 22. |
413-820
|
[4] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 23. |
700112886
|
[1] |
SPACER
|
CAS
|
| 24. |
700112876
|
[1] |
SUPPORT ASSY.
|
CAS
SUPPORT ASSEMBLY (Includes Ref: 21)
|
