神钢零件查询(BREAKER) - ATTACHMENT (N&B) - SK115SR & SK135SR - ASN YV04, YY04, YH04-03001 (9/04-) (01-029) - PLATE GROUP, FLOOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
398 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY03M00014F2 | [1] | PLATE GROUP, FLOOR (NIBBLER & BREAKER) | |
| . . | YY03M00014F3 | [1] | PLATE GROUP, FLOOR (BREAKER) | |
| . . | YY03M00014F4 | [1] | PLATE GROUP, FLOOR (2 PEDAL) | |
| . . | YY03M00014F5 | [1] | PLATE GROUP, FLOOR (EXTRA & BREAKER) | |
| 1. | YT03M01112P1 | [1] | SUPPORT | KOB |
| 3. | YN03M01201P1 | [1] | COVER | KOB |
| 5. | YN03M01062P3 | [2] | COVER | KOB |
| 6. | YT03M01077P2 | [1] | SUPPORT | KOB |
| 7. | ZM22C08020 | [7] | BOLT | KOBM08x1.25x20mm (Incls. Washer & Lockwasher) |
| 8. | ZM22C10025 | [2] | BOLT | KOBM10x1.50x25mm (Incls. Washer & Lockwasher) |
| 10. | YY26M00003P1 | [1] | FLOOR MAT | KOB(F2 ONLY) |
| 11. | YY26M00004P1 | [1] | FLOOR MAT | KOB(F3 ONLY) |
| 12. | YY26M00005P1 | [1] | FLOOR MAT | KOB(F4 ONLY) |
| 13. | YY26M00006P1 | [1] | FLOOR MAT | KOB(F5 ONLY) |
