神钢零件查询(BREAKER) - ATTACHMENT (N&B) - SK115SR & SK135SR - ASN YV04, YY04, YH04-03001 (9/04-) (02-007) - BOOM HOE, 4.6M (YY02B00157F2) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
664 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY02B00157F2 | [1] | BOOM ASSY, HOE 4.6M | |
| 2. | YX05B01026P1 | [2] | BUSHING | KOB Superseded by part number: |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONBOOM, HOE |
| 3-2. | YY02B01095P1 | [1] | BRACKET | KOB |
| 3-3. | YW42H01039P1 | [1] | BRACKET | KOB |
| 3-4. | 2416T14115 | [2] | BLOCK | KOB |
| 3-5. | YW42H01012P1 | [2] | BLOCK | KOB |
| 3-6. | YY02B01094P1 | [1] | BLOCK | KOB |
| 3-7. | YV02B01006P1 | [1] | BLOCK | KOB |
