沃尔沃零件查询MD5A; MD5B; MD5CElectrical SystemElectrical System and Instruments: BEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
274 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
841762
|
[1] |
Alternator
|
|
| 2. |
840380
|
[1] |
Pulley
|
|
| 4. |
838072
|
[1] |
Bracket
|
|
| 5. |
959219
|
[2] |
Hex. socket screw
|
|
| 6. |
941907
|
[2] |
Spring washer
|
|
| 7. |
958322
|
[1] |
V-belt
|
MO-30016, L=1300mm
|
| 7. |
958368
|
[1] |
Drive belt set
|
MO 30017-, L=1325mm
|
| 8. |
100338
|
[1] |
Hexagon screw
|
L=95mm
|
| 9. |
842350
|
[1] |
Spacer sleeve
|
L=9mm
|
| 10. |
945654
|
[1] |
Lock nut
|
|
| 11. |
959223
|
[1] |
Hex. socket screw
|
See group 2A
|
| 12. |
838073
|
[1] |
Tensioner
|
|
| 13. |
946036
|
[1] |
Lock nut
|
|
| 14. |
191172
|
[1] |
Washer
|
|
| 15. |
955299
|
[1] |
Hexagon screw
|
L=45mm
|
| 16. |
838060
|
[1] |
Starter motor
|
|
| 16. |
3803077
|
[1] |
Starter motor, exch
|
|
| 17. |
940280
|
[2] |
Spring washer
|
|
| 18. |
955339
|
[2] |
Hexagon screw
|
|
| 19. |
956079
|
[1] |
Cross recessed screw
|
|
| 20. |
824823
|
[1] |
Fuse box
|
|
| 21. |
838209
|
[1] |
Bracket
|
|
| 22. |
948424
|
[1] |
Screw
|
See group 2A
|
| 23. |
833927
|
[1] |
Thermo monitor
|
|
| 23A. |
957181
|
[1] |
Gasket
|
|
| 24. |
875813
|
[1] |
Contact
|
|
| 25. |
955945
|
[1] |
Toothed washer
|
|
| 26. |
190663
|
[1] |
Screw
|
|
| 27. |
948210
|
[1] |
Cable tie
|
(827353)
|
| 28. |
833930
|
[1] |
Cable block
|
|
| 29. |
833618
|
[1] |
Extension cable
|
L=2000mm
|
| 29. |
833619
|
[1] |
Extension cable
|
L=5000mm
|
| 30. |
833929
|
[1] |
Alarm panel
|
|
| 31. |
870980
|
[1] |
Main switch
|
|
| 32. |
243700
|
[1] |
Handle
|
|
| 32A. |
955783
|
[2] |
Hexagon nut
|
|
| 33. |
821042
|
[1] |
Sign
|
|
| 34. |
941907
|
[1] |
Spring washer
|
|
| 35. |
955782
|
[1] |
Hexagon nut
|
|
| 36. |
834397
|
[1] |
Voltmeter
|
|
| 37. |
834374
|
[1] |
Voltmeter
|
|
| 38. |
19923
|
[1] |
Bulb
|
|
| 39. |
808175
|
[1] |
Bulb socket
|
|
| 40. |
834400
|
[1] |
Tank gauge, drinking water
|
See group 9
|
| 40. |
|
|
|
|
| 41. |
840530
|
[1] |
Tachometer kit
|
MO 30000-
|
| 42. |
840518
|
[1] |
Tachometer
|
MO 30001-
|
| 43. |
1502028
|
[1] |
Tachometer sensor
|
|
| 44. |
840099
|
[1] |
Aluminium gasket
|
|
| 45. |
19923
|
[1] |
Bulb
|
|
| 46. |
808175
|
[1] |
Bulb socket
|
|
| 47. |
875819
|
[1] |
Switch
|
|
| 48. |
837726
|
[1] |
Knob
|
|
| 49. |
843002
|
[1] |
Nut
|
|
