沃尔沃零件查询MD5A; MD5B; MD5CEngineCamshaft and Valve Mechanism: CEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
260 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
838260
|
[1] |
Camshaft
|
|
| 2. |
838035
|
[1] |
Gear
|
|
| 3. |
910111
|
[1] |
Woodruff key
|
|
| 7. |
941906
|
[8] |
Spring washer
|
|
| 8. |
955270
|
[8] |
Hexagon screw
|
|
| 9. |
807393
|
[2] |
Tappet
|
|
| 10. |
838367
|
[1] |
Push rod
|
|
| 11. |
418298
|
[2] |
Rocker arm
|
|
| 13. |
418286
|
[2] |
Ball stud
|
Spec 867451, 867539., Included in rocker arms 418298 and 838188.
|
| 14. |
921781
|
[2] |
Hexagon nut
|
Spec 867451, 867539., Included in rocker arms 418298 and 838188.
|
| 15. |
400722
|
[2] |
Shim
|
|
| 16. |
914456
|
[2] |
Snap ring
|
|
| 17. |
838175
|
[1] |
Bearing bracket
|
|
| 18. |
951961
|
[1] |
Spring pin
|
|
| 19. |
829589
|
[1] |
Plug
|
|
| 20. |
838397
|
[1] |
Rocker arm shaft
|
|
| 21. |
941907
|
[1] |
Spring washer
|
|
| 22. |
948425
|
[1] |
Hex. socket screw
|
|
| 23. |
925053
|
[1] |
O-ring
|
|
| 26. |
838351
|
[1] |
Shaft
|
|
| 26A. |
914446
|
[2] |
Snap ring
|
MO-30016
|
| 26. |
838401
|
[2] |
Retaining ring
|
MO 30017-
|
| 27. |
803604
|
[1] |
Spring
|
|
| 29. |
945292
|
[1] |
Stud
|
|
| 30. |
940344
|
[1] |
Wing nut
|
|
| 31. |
838178
|
[1] |
Inlet valve
|
|
| 31. |
838179
|
[1] |
Exhaust valve
|
|
| 32. |
829867
|
[2] |
Guide sleeve
|
|
| 33. |
1306630
|
[1] |
Valve stem seal
|
For intake valve., (833347)
|
| 34. |
838081
|
[2] |
Valve spring
|
|
| 35. |
403314
|
[2] |
Valve spring washer
|
|
| 36. |
403315
|
[4] |
Lock
|
|
| 37. |
838399
|
[1] |
Timing gear casing
|
|
| 39. |
838062
|
[1] |
Gasket
|
|
| 40. |
833521
|
[1] |
Plug
|
|
| 41. |
957181
|
[1] |
Gasket
|
|
| 42. |
838070
|
[2] |
Guide sleeve
|
|
| 43. |
191172
|
[2] |
Washer
|
|
| 44. |
941907
|
[12] |
Spring washer
|
|
| 45. |
959227
|
[2] |
Hex. socket screw
|
L=50mm
|
| 45. |
941761
|
[10] |
Hex. socket screw
|
L=40mm
|
