沃尔沃零件查询MD5A; MD5B; MD5CEngineLubricating System: BEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
959 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1A. |
838359
|
[1] |
Oil pump
|
|
| 2A. |
829714
|
[2] |
Sealing ring
|
|
| 2B. |
838368
|
[1] |
Oil pipe
|
|
| 2C. |
838389
|
[1] |
Flange
|
|
| 2D. |
942000
|
[1] |
Hex. socket screw
|
|
| 2E. |
838358
|
[1] |
Gear
|
|
| 3A. |
941907
|
[2] |
Spring washer
|
|
| 5A. |
955297
|
[2] |
Hexagon screw
|
L=25mm, MO-30016
|
| 5. |
955295
|
[2] |
Hexagon screw
|
L=20mm, MO 30017-
|
| 6. |
838235
|
[1] |
Gasket
|
|
| 7. |
838129
|
[1] |
Sump
|
|
| 8. |
941906
|
[18] |
Spring washer
|
|
| 9. |
942001
|
[18] |
Hex. socket screw
|
|
| 10. |
838251
|
[1] |
Tube
|
|
| 11. |
838253
|
[1] |
Oil dipstick
|
|
| 12. |
949187
|
[1] |
O-ring
|
(955972)
|
| 13. |
418440
|
[1] |
Nipple
|
|
| 14. |
834337
|
[1] |
Oil filter
|
|
| 15. |
807078
|
[1] |
Pressure monitor
|
See group 3
|
| 29. |
3848300
|
[1] |
Filler pipe
|
|
| 30. |
3848303
|
[1] |
Oil filler cap
|
|
| 31. |
840072
|
[1] |
Gasket
|
|
