沃尔沃零件查询MD5A; MD5B; MD5CEngineManual Starter and Inst. Components: AEPC Volvo Penta Parts catalog
广数供应链运营团队, 15 02月, 2025，浏览：
747 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
838040
|
[1] |
Shaft
|
|
| 2. |
951991
|
[1] |
Spring pin
|
|
| 3. |
949303
|
[1] |
Key
|
|
| 4. |
833759
|
[1] |
Sealing ring
|
|
| 5. |
181119
|
[1] |
Ball bearing
|
|
| 6. |
838041
|
[1] |
Spacer ring
|
|
| 7. |
838042
|
[1] |
Spacer ring
|
|
| 8. |
963008
|
[1] |
Set screw
|
|
| 9. |
181119
|
[1] |
Ball bearing
|
|
| 10. |
838038
|
[1] |
Gear
|
|
| 11. |
941908
|
[1] |
Spring washer
|
|
| 12. |
955783
|
[1] |
Hexagon nut
|
|
| 13. |
955270
|
[4] |
Hexagon screw
|
|
| 14. |
941906
|
[4] |
Spring washer
|
|
| 15. |
838037
|
[1] |
Gear
|
|
| 16. |
838145
|
[1] |
Starting handle cran
|
|
