神钢零件查询(BREAKER) - ATTACHMENT (N&B) - SK115SR & SK135SR - ASN YV04, YY04, YH04-03001 (9/04-) (02-050) - CONNECTOR ASSY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
783 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LP43H00004F1 | [1] | CONNECTION | KOB |
| 1. | 2444P1744D2 | [1] | CONNECTION | KOB(No O-Ring supplied) |
| 2. | 2420T4404 | [1] | PLUG | KOB1-1/16" - 12 UNC |
| 3. | ZD12P02400 | [1] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| . . | LP43H00005F1 | [1] | CONNECTION | KOB |
| 1. | 2444P1745D2 | [1] | CONNECTION | KOB |
| 2. | 2420Z1228D4 | [1] | PLUG | KOB |
| . . | LP43H00006F1 | [1] | CONNECTION | KOB |
| 1. | LP43H01012P1 | [1] | CONNECTION | KOB |
| 2. | ZA82P28000 | [1] | PLUG | KOB |
