| . . | 24100J13832F7 | [1] | FRAME ASSY, UPP | |
| . . | 24100J13832F8 | [1] | FRAME ASSY, UPP | |
| . . | 24100J13832F9 | [1] | FRAME ASSY, UPP | |
| . . | 24100J13832F11 | [1] | FRAME ASSY, UPP | |
| 7. | 2420T6786 | [1] | BOLT,M12 x 1.75 x 25mm | KOBM12x1.75x25mm (Incls. Washer & Lockwasher), APPLICABLE: YQU01146-01159 Superseded by part number: ZM32C12025 |
| . . | 2420T6786 | [11] | BOLT,M12 x 1.75 x 25mm | KOBM12x1.75x25mm (Incls. Washer & Lockwasher), APPLICABLE: YQU?- YNU?- Superseded by part number: ZM32C12025 |
| 8. | 2420R561D1 | [1] | DIPSTICK | KOBDIPSTICK |
| 9. | 2420P1519D1 | [1] | PIPE | KOBPIPE |
| 10. | ZS13C10025 | [7] | CAPSCREW | KOBSCREW M10x1.50x25mm Superseded by part number: ZS18C10025 |
| 11. | ZS23C20055 | [12] | SCREW,Hex Socket Head, M20 x 55mm | KOBM20x2.5x55mm |
| 12. | ZS13C20110 | [30] | CAPSCREW | KOBSCREW M20x2.50x110mm |
| 13. | 2420T4564D1 | [3] | BOLT | KOBReamer -- M20x2.50x110mm |
| 14. | ZW13H10000 | [7] | WASHER | KOBID 11 x OD 24 x Th 3.2mm Superseded by part number: ZW16H10000 |
| 15. | ZW13H20000 | [33] | WASHER | KOBID 20 x OD 40 x Th 4.5mm |
| 17. | 2414T4703F1 | [1] | COVER | KOBCOVER ASSY |
| 17-1. | 2414P7583 | [1] | COVER | |
| 17-2. | 2427Z1343 | [1] | FOAM INSULATION | KOBINSULATION, SOUND |
| 19. | 2420T6787 | [10] | SCREW,M12 x 1.75 x 20mm | KOBM12x1.75x20mm (Incls. Washer & Lockwasher), APPLICABLE: YQU01146-01159 Superseded by part number: ZM32C12030 |
| 20. | 2427Z1392 | [1] | INSULATION, SOUND INSULATION, SOUND | INSULATION, SOUND INSULATION, SOUND |
| 21. | 2427Z1391 | [1] | FOAM INSULATION | KOBINSULATION, SOUND |
| 22. | 2427Z1393D1 | [1] | FOAM INSULATION | KOBINSULATION, SOUND |
| 23. | 2427Z1393D2 | [1] | FOAM INSULATION | KOBINSULATION, SOUND |
| 24. | 2427T919D1 | [1] | FOAM INSULATION | KOBINSULATION, SOUND |
| 25. | 2427T917D1 | [2] | FOAM INSULATION | KOBINSULATION, SOUND |
| 26. | 2479R1805 | [1] | INSULATOR INSULATION, SOUND | INSULATOR INSULATION, SOUND |
| 27. | 2479Z2216 | [1] | INSULATOR | KOBINSULATOR |
| 28. | 2479Z2218 | [1] | INSULATOR | KOBINSULATOR |
| 29. | 2479Z2407 | [1] | INSULATOR | KOBINSULATOR |
| 30. | 2418T12125 | [1] | PLATE | KOBPLATE Superseded by part number: YN52F01159P1 |
| 31. | 2416Z434 | [1] | PACKING | KOBRubber |
| 32. | 2414T4850F2 | [1] | COVER ASSY | KOBCOVER ASSY, Remarks: (F7 ONLY) |
| 32-2. | 2427Z1344 | [1] | FOAM INSULATION | KOBINSULATION, SOUND |
| 32-3. | 2416Z263D2 | [1] | FOAM INSULATION | KOBSHEET, RUBBER |
| 32-4. | 2414P8769 | [1] | COVER | |
| 34. | 24100P3750F1 | [1] | STAY | KOBSTAY ASSY |
| 34-1. | 2416P18523 | [1] | STAY | KOBSTAY |
| 34-2. | 2432T4113D2 | [1] | CLAMP | KOBCLAMP |
| 34-3. | ZS18C08040 | [2] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| 34-4. | ZW26X08000 | [2] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 35. | 2456R351 | [1] | MIRROR | KOBMIRROR |
| 36. | 2445T290 | [1] | SEAL | KOBSEAL, DUST Superseded by part number: YN52F01161P1 |
| 37. | 24100J11091F9 | [1] | HYDRAULIC MOTOR | KOBMOTOR ASSY, SWING, Remarks: P. 025-01 Superseded by part number: 24100J11091F10 |
| 38. | 2416T28046 | [1] | BRACKET BRACKET | BRACKET BRACKET |
| 42. | 2414T4934F2 | [1] | COVER ASSY, Remarks: (F8. F9. F11 ONLY) | |
| 42-2. | 2427Z1454 | [1] | INSULATION, SOUND | |
| 42-3. | 2416Z263D2 | [1] | FOAM INSULATION | KOBSHEET, RUBBER |
| 42-4. | 2414P8764 | [1] | COVER | |
| 44. | 2422J3755D6 | [1] | FRAME, UPP, Remarks: P. 014-50A (F7 ONLY) | |
| . . | 2422J3755D7 | [1] | FRAME, UPP, Remarks: (F8 ONLY) | |
| . . | 2422J3755D8 | [1] | FRAME, UPP, Remarks: (F9 ONLY) | |
| . . | 2422J3755D10 | [1] | FRAME, UPP, Remarks: (F11 ONLY) | |
| 44-1. | ZS83C20020 | [1] | SCREW | KOBSet -- M20x2.50x20mm |
| 44-2. | 2405T1256 | [2] | BUSHING | KOBBUSHING |
| 44-3. | 2414T2784 | [1] | COVER | KOBID 95 X OD 146.4 x Th 06mm |
