凯斯零件查询(LB324P) - BALER (9/12-) (31.205.010) - FLYWHEEL Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
460 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84597854
|
[1] |
FLYWHEEL,776mm OD
|
ZED
Incl 13 - 18, Serial Range: -C084
|
| 1. |
47392784
|
[1] |
BALER FLYWHEEL,776mm OD
|
ZED
Incl 13, Start Serial: D085
|
| 1. |
84593776
|
[1] |
FLYWHEEL,950mm OD
|
ZED
Incl 13 - 18, Serial Range: -C084
|
| 1. |
84579146
|
[1] |
BALER FLYWHEEL
|
ZED
Incl 13, Start Serial: D085
|
| 2. |
87660055
|
[1] |
INSERT
|
ZED
|
| 3. |
84555969
|
[1] |
SEAL
|
ZED
|
| 4. |
375400
|
[1] |
SEALING RING
|
ZED
|
| 5. |
370008
|
[1] |
SNAP RING,M50, Ext
|
NH
Superseded by part number: 8603209
|
| 6. |
853116
|
[2] |
TAPERED BEARING
|
ZED
Superseded by part number: 87555831
|
| 7. |
84557277
|
[1] |
FLANGE
|
ZED
|
| 8. |
62161
|
[2] |
LUBE NIPPLE,M8 x 1.25, Str
|
NH
|
| 9. |
84580734
|
[6] |
BOLT,Hex, M10 x 130mm, Cl 8.8
|
ZED
|
| 9. |
84577051
|
[6] |
BOLT,Hex, M10 x 130mm, Cl 10.9
|
ZED
|
| 10. |
84364722
|
[1] |
MARKER
|
ZED
, Serial Range: -C144
|
| 10. |
47830517
|
[1] |
MARKER
|
ZED
, Start Serial: D145
|
| 11. |
100037
|
[6] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
394630
|
[1] |
WASHER,13mm ID x 28mm OD x 4mm Thk
|
NH
Superseded by part number: 86625256
|
| 13. |
84555963
|
[1] |
BUSHING
|
ZED
|
| 14. |
84580611
|
[1] |
SPACER
|
ZED
|
| 14. |
84593889
|
[1] |
SPACER
|
ZED
|
| 15. |
280685
|
[6] |
HEX SOC SCREW,M12 x 40mm, Cl 12.9
|
NH
|
| 16. |
84555965
|
[1] |
SPACER
|
ZED
|
| 17. |
140046
|
[3] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 18. |
43158
|
[3] |
BOLT,Hex, M12 x 80mm, Cl 8.8
|
NH
|
| 19. |
47570066
|
[1] |
PLATE
|
ZED
, Serial Range: -F091120
|
| 20. |
353223A1
|
[2] |
WASHER
|
CAS
, Start Serial: D091
|
| 21. |
47609984
|
[2] |
BOLT,Hex, M8 x 30mm, Cl 12.9
|
ZED
, Serial Range: -F091120
|
