| 1. |
84525799
|
[1] |
BRAKE BAND,75mm W x 3.3mm Thk
|
ZED
, Serial Range: -C071 Superseded by part number: 47436753
|
| 1. |
47436753
|
[1] |
BRAKE BAND,75mm W x 5mm Thk
|
ZED
, Serial Range: -F072121
|
| 1. |
47691766
|
[1] |
BRAKE BAND
|
ZED
, Serial Range: -F122136
|
| 1. |
47843702
|
[1] |
BRAKE BAND
|
ZED
, Start Serial: D137
|
| 1. |
84525800
|
[1] |
BRAKE BAND,75mm W x 3.3mm Thk
|
ZED
, Serial Range: -C120
|
| 1. |
47691764
|
[1] |
BRAKE BAND
|
ZED
, Start Serial: D121
|
| 2. |
84573463
|
[1] |
HANDLE
|
ZED
|
| 2. |
84557945
|
[1] |
HANDLE
|
ZED
, Serial Range: -C035 Superseded by part number: 84573463
|
| 2. |
47985673
|
[1] |
HANDLE
|
ZED
|
| 3. |
9837774
|
[1] |
HANDLE GRIP
|
ZED
|
| 4. |
87549340
|
[1] |
SPINDLE
|
ZED
|
| 5. |
9837781
|
[1] |
PIN,30mm OD x 80mm L
|
ZED
|
| 6. |
9837784
|
[1] |
ROD
|
ZED
|
| 7. |
84989876
|
[1] |
BUSHING,11mm ID x 20mm OD x 14mm L
|
ZED
|
| 8. |
323307
|
[1] |
CLAMP
|
ZED
|
| 9. |
9837782
|
[1] |
BOLT,Hex, M12 x 1.75 x 230mm, Cl 8.8
|
ZED
, Serial Range: -C035
|
| 9. |
84439922
|
[1] |
BOLT,Hex, M12 x 240mm, Cl 8.8
|
ZED
, Start Serial: D036
|
| 10. |
140084
|
[1] |
WASHER
|
ZED
|
| 11. |
9706685
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 12. |
370002
|
[2] |
CIRCLIP,M25, External
|
NH
|
| 13. |
388270
|
[1] |
SPACER,31mm ID x 50mm OD x 4mm L
|
ZED
|
| 14. |
86511042
|
[1] |
SCREW,Pan Head, M4 x 0.7 x 16mm, Cl 4.8
|
ZED
Superseded by part number: 13272214
|
| 15. |
9824840
|
[1] |
WASHER,4.3mm ID x 9mm OD x 0.8mm Thk
|
NH
Superseded by part number: 89824840
|
| 16. |
100012
|
[1] |
NUT,M4 x 0.7, Cl 8
|
NH
Superseded by part number: 57121
|
| 17. |
322355
|
[1] |
BELLEVILLE WASHER,M4 Bolt Size x 10mm OD x 0.9mm Thk
|
NH
|
| 18. |
9706704
|
[1] |
BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8
|
NH
|
| 19. |
140042
|
[1] |
WASHER,11mm ID x 34mm OD x 3mm Thk
|
GI
|
| 20. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 21. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 22. |
86622500
|
[2] |
WASHER,13.49mm ID x 22.2mm OD x 1.36mm Thk
|
PA
|
| 23. |
9837786
|
[2] |
HEX SOC SCREW,M12 x 20mm, Cl 8.8, Full Thd
|
ZED
|
| 24. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 25. |
84560148
|
[1] |
REINFORCEMENT
|
ZED
|
| 25. |
84558715
|
[1] |
REINFORCEMENT
|
ZED
|
| 26. |
300662
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 80mm, Cl 8.8
|
NH
, Serial Range: -C035
|
| 26. |
334070
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 90mm, Cl 8.8
|
PA
, Start Serial: D036 Superseded by part number: 80334070
|
| 27. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 28. |
337475
|
[4] |
NUT,M12, Cl 10
|
BHB
|
| 29. |
86592701
|
[4] |
WASHER,13mm ID x 35mm OD x 5mm Thk
|
ZED
, Start Serial: D036
|
| 30. |
335872
|
[1] |
WASHER,4.1mm ID x 15mm OD x 1.6mm Thk
|
ZED
, Start Serial: D072
|
