凯斯零件查询(LB324P) - BALER (9/12-) (31.220.060) - MAIN GEARBOX, ARM TO PLUNGER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
952 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84074482
|
[1] |
CAP
|
ZED
|
| 2. |
370026
|
[2] |
SNAP RING,M100 x 3mm Thk, Internal
|
ZED
Superseded by part number: S301572
|
| 3. |
84074466
|
[2] |
CIRCLIP
|
ZED
|
| 4. |
9516384
|
[2] |
SPHERICAL BEARING,55mm ID x 100mm OD x 25mm W
|
ZED
|
| 5. |
84074452
|
[2] |
HUB
|
ZED
Incl in 15 Superseded by part number: 84587348
|
| 6. |
84074472
|
[2] |
SHIM,85.3mm ID x 99.8mm OD x 1mm Thk
|
ZED
|
| 7. |
84817177
|
[2] |
RING
|
ZED
|
| 8. |
84346505
|
[1] |
CRANK
|
ZED
|
| 9. |
84800770
|
[4] |
BOLT,Hex, M27 x 2 x 190mm, Cl 12.9
|
ZED
|
| 10. |
84819390
|
[4] |
WASHER
|
ZED
|
| 11. |
84074479
|
[1] |
SEALING RING
|
ZED
|
| 12. |
84800771
|
[1] |
ARM
|
ZED
|
| 13. |
84346506
|
[1] |
CRANK
|
ZED
Incl 8, 5
|
| 14. |
84800773
|
[1] |
ARM
|
ZED
Incl 12, 5
|
| 15. |
84587348
|
[2] |
HUB
|
ZED
Incl 3-5 Superseded by part number: 84074452
|
