凯斯零件查询(LB324P) - BALER (9/12-) (35.565.020) - KNIFE DRAWER, HYDRAULICS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
135 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84023899
|
[1] |
SEAL KIT
|
ZED
|
| 2. |
84039383
|
[1] |
SUPPORT
|
ZED
|
| 3. |
84039381
|
[1] |
BRACKET
|
ZED
|
| 4. |
84039382
|
[1] |
UNIVERSAL JOINT
|
ZED
|
| 5. |
84807314
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 18mm Rod, 140mm Stroke
|
ZED
Incl 1, 13
|
| 6. |
84078953
|
[1] |
COVER PLATE
|
ZED
|
| 7. |
412118
|
[2] |
CLEVIS PIN,12mm OD x 65mm L
|
NH
|
| 8. |
378245
|
[6] |
WASHER,13mm ID x 28.5mm OD x 2.7mm Thk
|
NH
|
| 9. |
355518
|
[1] |
PIN,M12 x 35
|
ZED
|
| 10. |
130003
|
[3] |
COTTER PIN,3mm OD x 30mm OAL
|
ZED
|
| 11. |
364164
|
[1] |
THIN NUT,Thin, M16 x 1.5, Cl 04
|
ZED
Superseded by part number: 10791411
|
| 12. |
370002
|
[1] |
CIRCLIP,M25, External
|
NH
|
| 13. |
427034
|
[1] |
SEAL KIT
|
ZED
|
