凯斯零件查询(LB324P) - BALER (9/12-) (35.565.030) - KNIFE DRAWER, HYDRAULIC LINES Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
259 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87492506
|
[2] |
FLEXIBLE HOSE,6.3mm ID x 2500mm L, SAE 100R1
|
ZED
|
| 2. |
87493574
|
[2] |
NUT
|
ZED
|
| 3. |
84292377
|
[1] |
HYD TUBE
|
ZED
|
| 4. |
84292379
|
[1] |
HYD TUBE
|
ZED
|
| 5. |
84350868
|
[2] |
HYD TUBE,6.35mm ID x 1120mm L, SAE 100R16
|
ZED
|
| 6. |
412152
|
[3] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 7. |
84292497
|
[1] |
HYD TUBE
|
ZED
|
| 8. |
84292495
|
[1] |
HYD TUBE
|
ZED
|
| 9. |
84041508
|
[2] |
HYD CONNECTOR
|
ZED
|
| 10. |
84819675
|
[2] |
PUSH-PULL COUPLING
|
ZED
|
| 11. |
84819676
|
[2] |
PROTECTION CAP
|
ZED
|
| 12. |
386215
|
[2] |
HYD CONNECTOR
|
ZED
|
| 13. |
335172
|
[2] |
HYD CONNECTOR,M14 x 1.5 x M14 x 1.5
|
ZED
|
| 14. |
9839227
|
[1] |
HYDRAULIC HOSE,6.35mm ID x 345mm L
|
ZED
|
| 15. |
9839226
|
[1] |
HOSE
|
ZED
|
| 16. |
365947
|
[1] |
ORIFICE
|
ZED
|
| 17. |
430357
|
[6] |
CLAMP
|
DUB
|
| 18. |
431941
|
[3] |
SUPPORT
|
DUB
|
| 19. |
120056
|
[3] |
BOLT,M6 x 1.0 x 54.15mm, Cl 8.8
|
NH
|
| 20. |
86588450
|
[3] |
WASHER,6.6mm ID x 12mm OD x 1.6mm Thk
|
ZED
|
| 21. |
9507811
|
[1] |
CONDUIT
|
CUR
, Start Serial: D072 Superseded by part number: 9507811BR
|
