| . . | LC30H00004F1 | [1] | HYD LINES, PUMP | |
| 1. | LC30H01009P1 | [1] | HOSE | KOB |
| 2. | ZX30U12074 | [1] | HOSE | |
| 3. | ZX30U12080 | [1] | HOSE | |
| 4. | ZX30H12165 | [1] | HOSE | KOB |
| 5. | ZX30H12155 | [1] | HOSE,Hyd, 19mm ID x 31.20mm OD x 155mm L | KOB |
| 6. | ZC16X09100 | [2] | CLIP | KOBClamp, Hose -- Min 80 x Max 101mm |
| 7. | ZC26X15009 | [1] | CLAMP | KOB |
| 8. | ZS18C12030 | [4] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 9. | ZS18C08040 | [1] | SCREW,Hex, M8 x 40mm | KOBM08x1.25x40mm |
| 10. | ZS18C10090 | [8] | SCREW,Hex, M10 x 90mm | KOBM10x1.50x90mm |
| 11. | ZS18C10035 | [4] | SCREW,Hex, M10 x 35mm | KOBM10x1.50x35mm |
| 12. | ZS28C12030 | [4] | SCREW,Hex Socket Head, M12 x 30mm | KOBScrew -- M12x1.75x30mm |
| 13. | ZS18C10075 | [4] | SCREW,Hex, M10 x 75mm | KOBM10x1.50x75mm |
| 14. | ZW16H08000 | [1] | WASHER | KOBID 08 x OD 18 x Th 3.2mm |
| 15. | ZW16H10000 | [4] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 16. | ZW16H12000 | [4] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 17. | ZW16X10000 | [5] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 18. | ZW26X10000 | [8] | LOCK WASHER | KOBID 10 x OD 18 x Th 2.5mm |
| 19. | ZW26K12000 | [4] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 20. | YN03H01432P1 | [4] | BUSHING,28mm ID x 56mm OD x 70mm L | KOBSplit -- ID 28 x OD 38 x 70mm Long |
| 21. | YN03H01427P1 | [2] | CLAMP | KOB122.5x50x48mm |
| 22. | LC52S00002P1 | [2] | PRESSURE SWITCH | KOBSENSOR, PRESSURE (H.P.) (Replaced by LS52S00015P1) Superseded by part number: LC52S00002P2 |
| 22. | LS52S00015P1 | [2] | SENSOR | KOBPressure (High Pressure) (Incls. O-Ring ZD12P01400) |
| 22-0. | YY52S00033F2 | [1] | SENSOR | KOBKit Includes Ref 22 - 22-4 (Refer to SB S030-41-K003) |
| 22-1. | ZD12P01400 | [1] | O-RING | KOB |
| 22-2. | YN13E01610P1 | [1] | HARNESS | KOB(Added with new part # press switch) |
| 22-3. | LS30H01024P1 | [1] | HYD CONNECTOR | SM(Added with new part # press switch) |
| 22-4. | YT42H01128P1 | [1] | 90 ELBOW | KOB |
| 23. | YN30H01010P1 | [1] | ELBOW | KOB |
| 24. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 25. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 26. | 2436U1303F1 | [1] | PILOT VALVE | KOBVALVE DEVIDER FROW |
| 27. | ZD12P02600 | [3] | O-RING | KOBID 25.70 ± 0.26 x OD 32mm |
| 28. | ZD12A01800 | [4] | O-RING,1.78mm Thk x 18.77mm ID, Cl 6 | KOBID 18.77 ± 0.12 x OD 22.33mm |
| 29. | ZD11G07500 | [1] | O-RING,74.40mm ID x 80.60mm OD x 3.10mm | KOBID 74.40 ± 0.65 x OD 80mm |
| 30. | ZD12P01400 | [1] | O-RING | KOBID 13.80 ± 0.19 x OD 18mm |
| 31. | ZE13X12000 | [4] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) |
| 32. | ZF23B15000 | [1] | HYD CONNECTOR | KOB |
| 33. | ZA23F15006 | [1] | HYD CONNECTOR | KOB3/8"PF - M22x1.50 x 37mm Long (No O-Ring supplied) |
| 34. | ZG23F12016 | [4] | HYD CONNECTOR | KOB1 3/16" 12UN-1" PT x 48mm Long (Incls. O-Ring 237-6016) |
| 35. | YN30H01043P1 | [1] | FLANGE | |
| 36. | LC30H01019P1 | [1] | TUBE | |
| 37. | LC30H01020P1 | [1] | TUBE | |
| 38. | LC30H01018P1 | [1] | SUPPORT | KOBSUPPORT |
| 39. | ZC16X10000 | [2] | CLIP | KOBClamp, Hose -- Min 87 x Max 113mm |
| 40. | LC30H01021P1 | [1] | SUPPORT | |
