| . . | LC03H00004F1 | [1] | HYD LINES, UPP | |
| 1. | LC03H01063P1 | [1] | RIGID TUBE | KOB |
| 2. | LC03H01062P1 | [1] | RIGID TUBE | KOB |
| 3. | LC03H01037D1 | [1] | FLEXIBLE HOSE | KOB |
| 4. | LC03H01025D1 | [1] | HOSE | KOB |
| 5. | HH25R16016G2 | [1] | HYD CONNECTOR | KOB1" PF x 81mm Long (Incls. O-Ring ZD12P02900) |
| 5-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 6. | 2444Z3203 | [1] | ELBOW | KOBELBOW Superseded by part number: HH35X16016G1 |
| 6-1. | ZD12P02900 | [1] | O-RING | KOBID 28.70 ± 0.29 x OD 35mm |
| 7. | 24100P2599F1 | [1] | VALVE | KOB Superseded by part number: 24100P2599F2 |
| 7-1. | 2436N184 | [1] | BODY,VALVE | |
| 7-2. | 2436P183 | [1] | VALVE | KOB |
| 7-4. | ZR16X05000 | [1] | RING | KOBRetaining -- ID 50 x OD 64 x Th 2.0mm |
| 7-5. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 7-6. | ZD12P04400 | [1] | O-RING | KOB |
| 7-8. | ZD11G05000 | [2] | O-RING,3.1mm Thk x 49.4mm ID, 70 Duro | KOBO-Ring -- ID 49.40 ± 0.45 x OD 55mm |
| 7-9. | ZD85P04400 | [1] | BACK-UP RING | KOB |
| 7-10. | ZD75P05000 | [1] | RING | KOB |
| 8. | LC03H01064P1 | [1] | BRACKET | KOB Superseded by part number: LC03H01238P1, 87336029 |
| 9. | LC03H01051P1 | [1] | U-BRACKET | KOB Superseded by part number: LC03H01218P1, 77261677 |
| 10. | LC03H01046P1 | [1] | CLAMP | KOB |
| 11. | LC03H01022D2 | [1] | SPACER | KOB |
| 12. | ZE13X16000 | [8] | FLANGE | KOBClamp, Half -- (Incls. Capscrew & Lockwasher) |
| 13. | ZD12P03400 | [5] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOBID 33.70 ± 0.33 x OD 40mm |
| 14. | ZD12A02100 | [2] | O-RING | KOBID 23.52 ± 0.15 x OD 27.08mm |
| 15. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 16. | ZS18C12035 | [6] | SCREW,Hex, M12 x 35mm | KOBM12x1.75x35mm |
| 17. | ZS18C12070 | [1] | SCREW,Hex, M12 x 70mm | KOBM12x1.75x70mm |
| 18. | ZS28C12040 | [16] | SCREW,Hex Socket Head, M12 x 40mm | KOBM12x1.75x40mm |
| 19. | ZW16H10000 | [4] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 20. | ZW16H12000 | [6] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 21. | 2418T10357 | [3] | WASHER | KOBID 13 x OD 30 x Th 3.2mm Superseded by part number: 2418T12345 |
| 22. | ZW26K12000 | [20] | LOCK WASHER | KOBID 12 x OD 17.8 x Th 2.5mm |
| 23. | ZN18C12010 | [1] | NUT | KOBM12x1.75mm |
| 24. | LC03H01070P1 | [1] | SUPPORT | KOB |
| 25. | YN32H01066P1 | [1] | CLAMP | KOB94x38x31mm |
| 26. | YN03H01431P1 | [1] | BUSHING,28mm ID x 56mm OD x 70mm L | KOBSplit -- ID 28 x OD 38 x 70mm Long |
| 27. | ZS18C12055 | [1] | SCREW,Hex, M12 x 55mm | KOBM12x1.75x55mm |
| 28. | ZS28C12065 | [4] | SCREW,Hex Socket Head, M12 x 65mm | KOBM12x1.75x65mm |
