| .. | LC06H00018F1 | [1] | CONTROL LINES, PUMP | |
| 1. | 2420R349D180 | [1] | HOSE,6.35mm ID x 1800mm L | KOB1800mm Long (70-7/8 in) |
| 2. | 2420R349D220 | [1] | HOSE,2200.00 mm | KOB Superseded by part number: HX21E04220DX |
| 3. | 2420R349D095 | [1] | FLEXIBLE HOSE | KOB |
| 4. | 2420R349D045 | [1] | HOSE | KOB450mm Long (17-23/32 in) |
| 5. | 2420R537D055 | [1] | HOSE ASSY.,9.60mm ID x 550mm L | KOB |
| 6. | 2444R1119D048 | [1] | HOSE | KOB480mm Long (18-57/64 in) |
| 7. | ZH22X06000 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) (PF3/8) |
| 8. | HH25R08004G1 | [1] | HYD CONNECTOR | KOB1/4"PFx1/2"PFx36mm Long (Incls. O-Ring ZD12P01800) |
| 9. | ZH32X04000 | [3] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 10. | ZH32X06000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 11. | ZH32X12000 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOBElbow, 90° -- 3/4 PF (Incls. O-Ring 237-6012) |
| 12. | ZH42X12000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/4" x PF 3/4", O-Ring | KOB45° -- 3/4" PF (Incls. O-Ring 237-6012) |
| 13. | ZX22M12056 | [1] | HOSE | KOB Superseded by part number: ZX22M12060 |
| 14. | HH25R04004G5 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 15. | 2444Z2525 | [2] | HYD CONNECTOR | KOB1/4"PFx35mm Long (Incls. O-Ring ZD12P01100) Superseded by part number: 72217408 |
| 16. | 2444Z2336 | [1] | TEE | KOBTee -- 1/4"x3/8"x3/8"PF (Incls. O-Ring ZD12P01100) |
| 17. | ZS18C10030 | [2] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 18. | 2445R373F1 | [1] | ACCUMULATOR | KOB |
| 19. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 20. | YN50V00011F2 | [1] | FILTER | KOBAssembly, Inline |
| 21. | ZH42X06000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 3/8" x PF 3/8", O-Ring | KOB45° -- (Incls. O-Ring 237-6006) |
| 22. | ZE72X06000 | [1] | PLUG | KOB3/8" PF, (Incls. O-Ring ZD12P01400) |
| 23. | YN06H01026P1 | [2] | TEE | KOB |
| 24. | YN52S00016P2 | [2] | PRESSURE SWITCH | KOBNegative Control Superseded by part number: YN52S00016P3 |
| 25. | PY01P01043D6 | [5] | CABLE TIE,4.80mm W x 383mm L | KOBWire Ties -- 368mm Long |
| 26. | 2420Z2185 | [1] | GROMMET | KOB |
| 27. | 2418R676D1 | [1] | TUBE | KOBID 10.7 x OD 14.1 x 100mm Long (3-15/16 in) |
