神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK330, SK330LC DYNAMIC ACERA EXCAVATOR (9/04-) (01-027) - PLATE GROUP, FLOOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
561 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN03M00033F2 | [1] | PLATE GROUP, FLOOR (NIBBLER & BREAKER) | |
| . . | YN03M00033F3 | [1] | PLATE GROUP, FLOOR (BREAKER) | |
| . . | YN03M00033F4 | [1] | PLATE GROUP, FLOOR (2 PEDAL) (EXTRA+NIBBLER & BREAKER) | |
| . . | YN03M00033F5 | [1] | PLATE GROUP, FLOOR (2 PEDAL) (EXTRA+BREAKER) | |
| 2. | YN26M00020P1 | [1] | FLOOR MAT | KOB(F2 0NLY) |
| 3. | YN26M00021P1 | [1] | FLOOR MAT | KOB(F3 0NLY) |
| 4. | YN26M00025P1 | [1] | MAT, FLOOR (F4 ONLY) | |
| 6. | YN03M01335P1 | [1] | SUPPORT | KOB(F2, F3 ONLY) |
| 7. | YN03M01364P3 | [1] | COVER | KOBCOVER |
| 8. | YN03M01062P1 | [2] | COVER | KOB Superseded by part number: YN03M01479P1 |
| 9. | 2420R603D6 | [1] | GROMMET | KOB |
| 10. | ZM27C08025 | [7] | BOLT | KOBM08x1.25x25mm (Incls. Washer & Lockwasher) |
| 11. | ZM22C10030 | [2] | BOLT | KOBM10x1.50x30mm (Incls. Washer & Lockwasher), (F2, F3 Only) |
| 12. | YN03M01365P1 | [1] | COVER | KOB |
| 13. | ZM27C08030 | [1] | SCREW | KOBM08x1.25x30mm (Incls. Washer & Lockwasher) |
| 14. | YT21C01037D6 | [1] | TRIM PANEL | KOB120mm Long (4-23/32 in) |
| 15. | YN26M00028P1 | [1] | MAT, FLOOR (F5 ONLY) | |
