神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK330, SK330LC DYNAMIC ACERA EXCAVATOR (9/04-) (02-003) - HYD LINES, BOOM 6.5M (21FT 4IN) (BREAKER, NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
528 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC42H00014F1 | [1] | HYD LINES, BOOM 6.5M | |
| 3. | LC42H01062P1 | [1] | RIGID TUBE | KOB |
| 4. | LC42H01063P1 | [1] | RIGID TUBE | KOB |
| 5. | 2444R1166D7 | [2] | FLEXIBLE HOSE | KOB |
| 6. | LC42H01041D1 | [2] | HOSE | KOB |
| 7. | ZE72X16000 | [4] | PLUG | KOB(Incls. O-Ring ZD12P02900) |
| 8. | LS42H01018P1 | [4] | CLAMP,52mm ID, 12mm Bolt Hole, J Type | KOB |
| 9. | LS42H01019P1 | [8] | CLAMP | KOB |
| 11. | 2432T6076 | [8] | CLAMP | KOB Superseded by part number: LC42H01269P1 |
| 12. | LC42H01020P1 | [4] | BUSHING,34mm ID x 53mm OD x 68mm L | KOB |
| 13. | LC43H01013P1 | [6] | BUSHING,43mm ID x 52mm OD x 68mm L | KOB |
| 14. | ZD12P03800 | [6] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 15. | ZS18C12065 | [16] | SCREW,Hex, M12 x 65mm | KOBM12x1.75x65mm |
| 16. | ZS18C10030 | [12] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 17. | ZW16H12000 | [16] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 18. | ZW16H10000 | [12] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 19. | ZE13X20001 | [12] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) Superseded by part number: ZE13X20000 |
| 20. | ZS28C14050 | [24] | CAPSCREW,Hex Socket Head, M14 x 50mm | KOBSCREW M14x2.0x50mm |
| 21. | ZW26K14000 | [24] | LOCK WASHER | KOBID 14 x OD 21.8 x Th 3.5mm |
| 22. | LC42H01123P1 | [1] | RIGID TUBE | KOB |
| 23. | LC42H01124P1 | [1] | RIGID TUBE | KOB |
