| . . | LC12B00043F2 | [1] | ARM GROUP, 2.6M | |
| 1. | LC12B01063F1 | [1] | LINKAGE YOKE | KOBLINK ASSY, BUCKET |
| 1-1. | NSS | [1] | NOT SOLD SEPARAT | CONLINK, BUCKET |
| 1-2. | 2405T1215 | [2] | BUSHING,90mm ID x 105mm OD x 95mm L | KOB |
| 1-3. | LC12B01013P1 | [2] | BUSHING,90mm ID x 105mm OD x 102mm L | KOB |
| 4. | LC12B01052P1 | [2] | PIN,90mm OD x 653mm L | KOB |
| 7. | 2445R220D6 | [4] | SEAL,90mm ID x 105mm OD x 6mm Thk | KOBDust -- ID 90 X OD 105 x Th 6mm |
| 8. | 2445R138D7 | [2] | SEAL,80mm ID x 95mm OD x 4mm Thk | KOBDust -- ID 80 x OD 95 x Th 4mm |
| 9. | 2445R138D8 | [4] | SEAL,90mm ID x 105mm OD x 4mm Thk | KOBDust -- ID 90 x OD 105 x Th 4mm |
| 10. | 2445R138D10 | [2] | SEAL,110mm ID x 130mm OD x 4mm Thk | KOBDust -- ID 110 x OD 130 x Th 4mm |
| 11. | HS18C20145G1 | [1] | SCREW | KOBM20x2.5x145mm Superseded by part number: 77261219, HS18C20145G2 |
| 12. | HS18C20160G1 | [1] | SCREW | KOBM20x2.5x160mm Superseded by part number: 77261220, HS18C20160G2 |
| 13. | ZN18C20016 | [4] | NUT | KOBM20x2.5mm |
| 14. | ZG91S02000 | [7] | LUBE NIPPLE,1/8" NPT x 1/8" NPT | KOB1/8" PT -- Straight |
| 15. | B16T0442D3 | [1] | SHIM,150mm OD x 82mm ID x 1.2mm Thk | KOBID 82 x OD 150 x Th 1.2mm |
| 16. | B16T0442D4 | [1] | SHIM,82mm ID x 150mm OD x 1.6mm Thk | KOBID 82 x OD 150 x Th 1.6mm |
| 17. | B16T0442D6 | [1] | SHIM,150mm OD x 82mm ID x 2.3mm Thk | KOBID 82 x OD 150 x Th 2.3mm |
| 18. | B16T0442D40 | [2] | SHIM,92mm ID x 160mm OD x 0.9mm Thk | KOBID 92 x OD 160 x Th 0.9mm |
| 19. | B16T0442D13 | [2] | SHIM,160mm OD x 92mm ID x 1.2mm Thk | KOBID 92 x OD 160 x Th 1.2mm |
| 20. | B16T0442D14 | [2] | SHIM,160mm OD x 92mm ID x 1.6mm Thk | KOBID 92 x OD 160 x Th 1.6mm |
| 21. | B16T0442D15 | [2] | SHIM,160mm OD x 92mm ID x 2.3mm Thk | KOBID 92 x OD 160 x Th 2.3mm |
| 22. | 2444R1117D085 | [1] | HOSE,6.4mm ID x 850mm L | KOB850mm Long (33-29/64 in) |
| 23. | ZH32Z04002 | [1] | ELBOW | KOB90° -- 1/4" PF - 1/8" PT |
| 24. | 2432R225D3 | [1] | CLAMP | KOBSingle -- ID 10 x 35.8mm Long Superseded by part number: ZC46X10009 |
| 25. | ZW26X06000 | [1] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 26. | ZW16X06000 | [1] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 27. | ZN18C06005 | [1] | NUT | KOBM06x1.0mm |
| 28. | LC12B01049P1 | [1] | LINK | KOB |
| 29. | LC12B01050P1 | [1] | LINK | KOB |
| 30. | LC12B01051P1 | [1] | PIN,80mm OD x 539mm L | KOB |
| 31. | LC12B01053P1 | [1] | PIN,90mm OD x 539mm L | KOB |
