神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK330, SK330LC DYNAMIC ACERA EXCAVATOR (9/04-) (02-008) - ARM ASSY 3.3M (10FT 10IN) (BREAKER, NIBBLER & BREAKER) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
489 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC12B00035F2 | [1] | ARM ASSY 3.3M (BREAKER) | |
| . . | LC12B00035F3 | [1] | ARM | KOBARM ASSY 3.3M (NIBBLER & BREAKER) Superseded by part number: LC12B00035FL |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONARM (F2 ONLY) |
| 2-2. | YN43H01051P1 | [2] | BLOCK | KOB |
| 2-3. | LC02B01024P1 | [2] | BLOCK | KOB |
| 2-4. | LC12B01071P1 | [2] | BLOCK | KOB |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONARM (F3 ONLY) |
| 3-1B. | YN43H01051P1 | [2] | BLOCK | KOB |
| 3-1C. | LC02B01024P1 | [2] | BLOCK | KOB |
| 3-1D. | LC12B01071P1 | [2] | BLOCK | KOB |
| 3-2. | 2418T24749 | [1] | PLATE | KOBPLATE |
| 4. | LC12B01009P1 | [2] | BUSHING,90mm ID x 105mm OD x 117mm L | KOB |
| 5. | 2405T907 | [2] | BUSHING,80mm ID x 95mm OD x 85mm L | KOB |
| 6. | LC12B01046P1 | [2] | BUSHING,110mm ID x 130mm OD x 132mm L | KOB |
