神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK330, SK330LC DYNAMIC ACERA EXCAVATOR (9/04-) (02-009[02]) - ARM ASSY 3.3M (10FT 10IN) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
594 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC12B00040F2 | [1] | ARM | KOBASSY, 3. 3M (NIBBLER & BREAKER) Superseded by part number: LC12B00040FD |
| . . | LC12B00040F3 | [1] | ARM | KOBASSY, 3. 3M (EXTRA + NIBBLER & BREAKER Superseded by part number: LC12B00040FE |
| . . | LC12B00040F4 | [1] | ARM | KOBASSY, 3. 3M (EXTRA) Superseded by part number: LC12B00040F9 |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONARM (F2 ONLY) |
| 2-2. | YN43H01051P1 | [2] | BLOCK | KOB |
| 2-3. | LC02B01024P1 | [2] | BLOCK | KOB |
| 2-4. | LC12B01071P1 | [2] | BLOCK | KOB |
| 2-5. | 2418T24749 | [1] | PLATE | KOB |
| 3. | LC12B01009P1 | [2] | BUSHING,90mm ID x 105mm OD x 117mm L | KOB |
| 4. | 2405T907 | [2] | BUSHING,80mm ID x 95mm OD x 85mm L | KOB |
| 5. | LC12B01046P1 | [2] | BUSHING,110mm ID x 130mm OD x 132mm L | KOB |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONARM (F3 ONLY) |
| 6-2. | YN43H01051P1 | [2] | BLOCK | KOB |
| 6-3. | LC02B01024P1 | [2] | BLOCK | KOB |
| 6-4. | LC12B01071P1 | [2] | BLOCK | KOB |
| 6-5. | 2418T24749 | [1] | PLATE | KOB |
| 6-6. | 2416T9878 | [1] | BLOCK,M10 Thd Hole - 16mm Thk x 32mm W x 60mm L | KOB |
| 6-7. | 2416T9878D5 | [4] | CONNECTING BLOCK | KOB |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONARM (F4 ONLY) |
| 7-2. | 2416T9878D5 | [5] | CONNECTING BLOCK | KOB |
