神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK330, SK330LC DYNAMIC ACERA EXCAVATOR (9/04-) (02-010) - ARM ASSY,SHORT 2.6M (10FT 10IN) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
144 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | LC12B00044F5 | [1] | ARM | KOBASSY, SHORT 2. 6M (NIBBLER & BREAKER) Superseded by part number: LC12B00044FJ |
| . . | LC12B00044F6 | [1] | ARM | KOBASSY, SHORT 2. 6M (EXTRA + NIBBLER & BREAKER) Superseded by part number: LC12B00044FK |
| 2. | LC12B01009P1 | [2] | BUSHING,90mm ID x 105mm OD x 117mm L | KOB |
| 3. | 2405T907 | [2] | BUSHING,80mm ID x 95mm OD x 85mm L | KOB |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONARM, SHORT (F5 ONLY) |
| 8-2. | YN43H01051P1 | [2] | BLOCK | KOB |
| 8-3. | LC02B01024P1 | [2] | BLOCK | KOB |
| 8-4. | LC12B01071P1 | [2] | BLOCK | KOB |
| 8-5. | LC12B01093P1 | [1] | PLATE | |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONARM, SHORT (F6 ONLY) |
| 9-2. | YN43H01051P1 | [2] | BLOCK | KOB |
| 9-3. | LC02B01024P1 | [2] | BLOCK | KOB |
| 9-4. | LC12B01071P1 | [2] | BLOCK | KOB |
| 9-5. | LC12B01093P1 | [1] | PLATE | |
| 9-6. | 2416T9878D5 | [5] | CONNECTING BLOCK | KOB |
