| . . | LC43H00019F1 | [1] | HYD LINES, ARM 2.6M | |
| 1. | LC43H01048P1 | [1] | TUBE | |
| 2. | LC43H01049P1 | [1] | TUBE | |
| 3. | LC43H01011D4 | [2] | HOSE | KOB1600mm Long (63 in) |
| 4. | 24100P3133F1 | [2] | VALVE | KOBSTOP, 1 1/4 PF Thead British Standard Parallel Pipe(BSPP) |
| . . | 2420T4361 | [2] | PLUG | KOBNot Shown, Used when aux lines not in use. |
| 4-1. | 2436P317 | [1] | VALVE BODY | KOBBODY, VALVE Superseded by part number: 24100P3133F1 |
| 4-2. | 2436T311 | [1] | VALVE | KOB |
| 4-3. | ZR16X04000 | [1] | RING | KOBRetaining -- ID 37 x OD 40 x Th 1.8mm |
| 4-4. | ZS23C06010 | [1] | SCREW,Hex Socket Head, M6 x 10mm | KOBM06x1.0x10mm |
| 4-5. | ZD12G03500 | [1] | O-RING,34.40mm ID x 40.60mm OD x 3.10mm | KOBID 34.40 ± 0.33 x OD 40mm |
| 4-6. | ZD85G03500 | [1] | RING | KOBBack-Up -- ID 35 x OD 40 x Th 1.25mm |
| 4-7. | ZD12G04000 | [1] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 4-8. | ZD75G04000 | [1] | BACK-UP RING | KOBID 40 x OD 45 x Th 1.25mm |
| 4-9. | 2418T8945D1 | [1] | SPACER | KOBID 40 x OD 60 x Th 3.2mm |
| 4-10. | ZD11G04000 | [2] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 5. | LC43H01019P1 | [2] | HYD CONNECTOR | KOB |
| 6. | ZE13X20001 | [12] | CLAMP | KOBHalf -- (Incls. Capscrew & Lockwasher) Superseded by part number: ZE13X20000 |
| 7. | YN43H01150P1 | [2] | U-BRACKET | KOB |
| 8. | LS42H01018P1 | [8] | CLAMP,52mm ID, 12mm Bolt Hole, J Type | KOB |
| 9. | ZS18C08025 | [8] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 10. | ZS18C10025 | [4] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 11. | ZS18C10030 | [4] | SCREW,Hex, M10 x 30mm | KOBM10x1.50x30mm |
| 12. | ZS18C12045 | [4] | SCREW,Hex, M12 x 45mm | KOBM12x1.75x45mm |
| 13. | ZS28C14050 | [16] | CAPSCREW,Hex Socket Head, M14 x 50mm | KOBSCREW M14x2.0x50mm |
| 14. | ZS28C14070 | [8] | SCREW,Hex Socket Head, M14 x 70mm | KOBM14x2.0x70mm |
| 15. | ZN18C14011 | [8] | NUT | KOBM14x2.0mm |
| 16. | ZW16H10000 | [8] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 17. | YN43H01151P1 | [8] | WASHER | KOBID 8.5 x OD 23 x Th 4.5mm |
| 18. | YN43H01163P1 | [4] | WASHER | KOBID 13 x OD 30 x Th 6.0mm |
| 19. | ZW26X12000 | [4] | LOCK WASHER | KOBID 12 x OD 21 x Th 3.0mm |
| 20. | ZW26K14000 | [24] | LOCK WASHER | KOBID 14 x OD 21.8 x Th 3.5mm |
| 21. | LC43H01013P1 | [4] | BUSHING,43mm ID x 52mm OD x 68mm L | KOB |
| 22. | ZD12P03800 | [8] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
