斗山零件查询SWING MOTOR SOLAR 330LC-V Doosan parts catalog online
广数供应链运营团队, 15 02月, 2025，浏览：
643 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
2401-9291
|
[1] |
MOTOR;SWING
|
|
| 1. |
0809-198
|
[1] |
RING;STOP
|
|
| 10. |
1321-128
|
[1] |
PISTON ASS'Y
|
|
| 11. |
7598-033
|
[4] |
PLATE;FRICTION
|
|
| 12. |
7598-034
|
[4] |
PLATE;SEPARATION
|
|
| 13. |
1320-137
|
[1] |
PISTON
|
|
| 14. |
0200-158
|
[1] |
O-RING
|
|
| 15. |
0200-159
|
[2] |
O-RING
|
|
| 16. |
1390-166
|
[19] |
SPRING
|
|
| 17. |
0719-072
|
[4] |
RING;TEFLON
|
|
| 18. |
1390-175
|
[4] |
SPRING
|
|
| 19. |
1391-130
|
[4] |
BUSHING
|
|
| 2. |
1399-210
|
[1] |
RING;INNER
|
|
| 20. |
8320-001
|
[3] |
PLUG PT1/4
|
|
| 21. |
0576-061
|
[1] |
BOLT;SOCKET M14X90
|
|
| 22. |
1320-158
|
[2] |
PISTON
|
|
| 23. |
1303-293
|
[1] |
COVER
|
|
| 24. |
0522-143
|
[2] |
PIN;PARALLEL
|
|
| 25. |
0522-145
|
[1] |
PIN;LOCK
|
|
| 26. |
1313-182
|
[1] |
PLATE;BALANCE
|
|
| 27. |
0682-136
|
[1] |
BEARING;NEEDLE
|
|
| 28. |
0809-199
|
[1] |
RING;STOP
|
|
| 29. |
0207-002
|
[2] |
O-RING
|
|
| 3. |
0722-137
|
[1] |
SEAL;OIL
|
|
| 30. |
3537-218
|
[2] |
RELIEF ASS'Y
|
|
| 31. |
0576-034
|
[7] |
BOLT;SOCKET
|
|
| 32. |
3526-327
|
[2] |
CAP
|
|
| 33. |
3590-288
|
[2] |
SPRING
|
|
| 34. |
8202-021
|
[2] |
O-RING
|
|
| 35. |
0859-229
|
[2] |
RING;BACK UP
|
|
| 36. |
3513-154
|
[2] |
CHECK
|
|
| 37. |
1329-111
|
[1] |
TIME DELAY VALVE
|
|
| 38. |
0576-054
|
[3] |
BOLT;SOCKET
|
|
| 4. |
0671-135
|
[1] |
BEARING;TAPER
|
|
| 5. |
1311-297
|
[1] |
HOUSING
|
|
| 6. |
1398-153
|
[1] |
PLATE;CAM
|
|
| 7. |
1398-154
|
[1] |
PLATE;RETURN
|
|
| 8. |
1390-174
|
[1] |
SPRING
|
|
| 9. |
1318-182
|
[1] |
CYLINDER
|
|
