神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK70SR-1E/SK70SR-1ES ASN YT04-07001 (9/04-) (01-040) - PLATE GROUP, FLOOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
107 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT03M00027F2 | [1] | PLATE GROUP, FLOOR (NIBBLER & BREAKER) | |
| . . | YT03M00027F3 | [1] | PLATE GROUP, FLOOR (BREAKER) | |
| . . | YT03M00027F4 | [1] | PLATE GROUP, FLOOR (2 PEDAL) | |
| . . | YT03M00027F5 | [1] | PLATE GROUP, FLOOR (EXTRA & BREAKER) | |
| 1. | YT03M01112P1 | [1] | SUPPORT | KOBF2 & F3 ONLY |
| 3. | YN03M01201P1 | [1] | COVER | KOBF2 & F3 ONLY |
| 5. | YN03M01062P3 | [2] | COVER | KOB |
| 6. | YT03M01077P2 | [1] | SUPPORT | KOB |
| 7. | ZM22C08020 | [7] | BOLT | KOBM08x1.25x20mm (Incls. Washer & Lockwasher) |
| 8. | ZM22C10025 | [2] | BOLT | KOBM10x1.50x25mm (Incls. Washer & Lockwasher), F2 & F3 Only |
| 10. | YT26M00023P1 | [1] | MAT | KOBF2 ONLY |
| 11. | YT26M00024P1 | [1] | MAT | KOBFLOOR, F3 ONLY |
| 12. | YT26M00025P1 | [1] | MAT | KOBF4 ONLY |
| 13. | YT26M00026P1 | [1] | MAT | KOBFLOOR, F5 ONLY |
