神钢零件查询(BREAKER) - NIBBLER/BREAKER ATTACHMENT - SK70SR-1E/SK70SR-1ES ASN YT04-07001 (9/04-) (01-045[02]) - CONTROLLER ASSY (HAND CONTROL) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
978 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YT22E00032F6 | [1] | CONTROLLER ASSY | |
| 8. | EN24S00008P1 | [1] | RELAY | KOB(5 Spade Relay) |
| 14. | ZM61C06012 | [1] | BOLT | KOBM06x1.0x12mm (Incls. Washer & Lockwasher) |
| 23. | ZW16X06000 | [1] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 33. | YT14E00023FA | [1] | HARNESS ASSY, CAB | |
| 33-8. | YT14E01071P1 | [1] | WIRE HARNESS | KOB |
| 38. | LC24S00001P1 | [1] | RELAY | KOB(5 Spade Relay) - Travel Alarm |
